EVAL-AD1940MINIB

SIGMASTUDIO SOFTWARE INTERFACE

The AD1940 SigmaDSP is controlled by Analog Devices'
SigmaStudio Software. This software allows the developer to
graphically build a fully customized audio signal processing
flow. SigmaStudio generates run-time DSP code that is
downloaded to the SigmaDSP through its SPI control port.
This connection on the evaluation board is header J2.

SOFTWARE INSTALLATION

The evaluation board cannot be run with a PC until the
SigmaStudio software has been installed. SigmaStudio must be
installed on a PC running Windows 2000 or XP. The following
steps should be taken to properly install the software and
drivers.
1. Insert the SigmaStudio CD and browse the disc.
2.
Install Microsoft .NET Framework version 1.1
Double-Click dotnetfx.exe
.NET installation can be skipped if ver1.1 or newer
has already been installed from
www.windowsupdate.com or
http://www.microsoft.com/net/
3. Install SigmaStudio - double-click setup.exe and
follow the prompts to install.
4. Restart the PC if the parallel port is to be used for
communication.

HARDWARE SETUP - USB

The steps below explain how to set up the USB connection on a
PC.
Use the included USB cable to make a connection
1.
between the USB Adapter board and an available USB
port on your computer.
Downloaded from Elcodis.com electronic components distributor
Windows should recognize the device, and the Found
2.
New Hardware Wizard will appear on your screen.
Select Install from a list or specific location
3.
(Advanced), and then click on Next.
Select Search for the best driver in these locations,
4.
then make sure Search removable media (floppy, CD-
ROM...) is unchecked, and Include this location in
the search is checked.
Click the Browse button.
5.
Browse to the USB drivers folder. By default, it should
6.
be located at C:\Program Files\Analog
Devices\Sigma Studio\USB Drivers.
Click OK.
7.
Click Next to begin the installation.
8.
Windows will tell you that the software has not passed
9.
Windows Logo testing. Click Continue Anyway.
When the installation is complete, click Finish.
10.

USING SIGMASTUDIO

The AD1940 does not pass an audio signal on power up. First,
the user must write to bit 9 of the DSP Core Control Register,
which will allow data to pass from input to output. This
procedure may be done manually, but this bit is always set to 1
after the program and parameter loading procedure is
completed by clicking the Link-Compile-Download button in
SigmaStudio. For more information about using SigmaStudio
with the evaluation board, please read the software's online
help document.
Software updates are provided via Analog Devices' FTP site.
Please e-mail SigmaDSP@analog.com for login information.
