INA260EVM-PDK Hardware

2 INA260EVM-PDK Hardware
Figure 2-1 shows the overall system setup for the INA260EVM-PDK. To monitor the power source, connect the
power source to the EVM input terminals. The computer runs the GUI software that enables power to the INA260
and communicate with the device. The user can send commands through the USB port of the computer to the
SM-USB-DIG board to translate these commands into I
With power enabled, the INA260 responds to these I
SM-USB-DIG board over the I
data back to the computer, where it is then appropriately processed and displayed to the user.
T1
V
V
SUPPLY
T2
I
LOAD
LOAD
6 INA260EVM-PDK (Rev A)
2
C. The SM-USB-DIG converts the received data to USB format and sends the
SCL
SDA
INA260EVM
ALERT
BUS
PCB
POWER
GND
Figure 2-1. INA260EVM-PDK Hardware Setup
Copyright © 2023 Texas Instruments Incorporated
2
C format before sending the commands to the EVM.
2
C commands by sending the requested data back to the
SM-USB-DIG
Controller
SBOU180A – NOVEMBER 2016 – REVISED MARCH 2023
www.ti.com
INA260EVM GUI
I
11.1 A
LOAD
USB DATA
V
6.02 V
BUS
POWER
P
66.82 W
LOAD
GND
