I D M - L 3 5 R D K Q U I C K S T A R T
Stellaris® Intelligent Display Module with 3.5"
Landscape Display (IDM-L35) RDK
Stellaris reference design kits (RDKs) from Texas Instruments accelerate product
development by providing ready-to-run hardware, example software, and comprehensive
documentation including hardware design files. The Intelligent Display Module with 3.5"
Landscape Display (IDM-L35) is a highly integrated QVGA touch-panel module for
automation and instrumentation applications. The compact design is based on the LM3S1958
Stellaris microcontroller. The example applications include source code exercising the various
peripherals provided on the module and illustrating use of the Stellaris® Peripheral Driver
Library and Stellaris® Graphics Library. Development of software for the IDM-L35 is
simplified by using StellarisWare® software and ARM development tools from our tools
partners.
Installing and Using the IDM-L35 RDK
Kit Contents
The IDM-L35 RDK includes the following items:
• Intelligent 3.5" Landscape QVGA Touch Panel (MDL-IDM-L35) with metal standoffs
• JTAG debug adapter (20-pin to 10-pin)
• USB-to-TTL serial cable
• Reference Design Kit CD containing this Quickstart Guide, a User's Manual, example
source code, peripheral driver library, graphics library, and hardware design files
Rev. 1.1
1
Advertisement
Related Manuals for Texas Instruments Stellaris IDM-L35
Summary of Contents for Texas Instruments Stellaris IDM-L35
- Page 1 Stellaris® Intelligent Display Module with 3.5” Landscape Display (IDM-L35) RDK Stellaris reference design kits (RDKs) from Texas Instruments accelerate product development by providing ready-to-run hardware, example software, and comprehensive documentation including hardware design files. The Intelligent Display Module with 3.5”...
- Page 2 I D M - L 3 5 R D K Q U I C K S T A R T Quickstart Application The IDM-L35 RDK comes preprogrammed with a quickstart application. Once you have powered the board, this application runs automatically. The application provides a security keypad to allow access to a door.
- Page 3 I D M - L 3 5 R D K Q U I C K S T A R T Installing the Virtual COM Port Driver 1. When you plug in the USB-to-serial cable for the first time, Windows starts the Found New Hardware Wizard and asks if it should attempt to install the software automatically or from a specified location.
- Page 4 I D M - L 3 5 R D K Q U I C K S T A R T 2. Make sure the IDM-L35 Documentation and Software CD that came with the Reference Design Kit is in your CD-ROM drive. Select “Search for the best driver in these locations,”...
- Page 5 I D M - L 3 5 R D K Q U I C K S T A R T 4. The Found New Hardware Wizard appears one more time. This is to install the drivers for the “USB Serial Port.” Again, follow the same instructions to install the drivers for this device.
- Page 6 I D M - L 3 5 R D K Q U I C K S T A R T 3. On your terminal program, type help followed by “Enter” to see a list of commands supported via the serial command line. 4.
- Page 7 I D M - L 3 5 R D K Q U I C K S T A R T IDM-L35 Example Applications The RDK-IDM-L35 Firmware Development Package includes several example applications for the IDM-L35. If you installed the software to the default installation path of C:\StellarisWare, you can find the example applications for the IDM-L35 in “C:\StellarisWare \boards\rdk-idm-l35”.
