- Page 1 INA260EVM-PDK INA260 Evaluation Module and Product Demonstration Kit User's Guide Literature Number: SBOU180 November 2016...
-
Page 2: Table Of Contents
..................... Configuration Tool ......................Results Bar ....................... Graph Tool ......................Registers Tool ....................INA260EVM Documentation ........................ Schematic ......................PCB Layout ......................Bill of Materials Table of Contents SBOU180 – November 2016 Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated... - Page 3 Configuring the Alert Pin ......................INA260 Results Bar ......................Graph Tool Page ....................... Registers Tool Page ....................INA260EVM Schematic ............... INA260EVM PCB Top Layer (Component Side) SBOU180 – November 2016 List of Figures Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
- Page 4 Signal Definition of J4 on INA260EVM Board ..................INA260 I C Address Configuration ................INA260EVM Test Board Jumper Functions .................... Bill of Materials: INA260EVM List of Tables SBOU180 – November 2016 Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
-
Page 5: Overview
The INA260EVM-PDK, which consists of the INA260EVM and SM-USB-DIG controller board, is a platform for evaluating the features and performance of the INA260 under various signal and supply conditions. This document gives a general overview of the INA260EVM-PDK, and describes the features and functions to be considered when using it. -
Page 6: Ina260Evm-Pdk Contents
Table 1. INA260EVM Kit Contents Item Quantity INA260EVM PCB test board SM-USB-DIG platform PCB USB extender cable Figure 1. Hardware Included with the INA260EVM Kit INA260EVM-PDK and Software Tutorial SBOU180 – November 2016 Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated... -
Page 7: Ina260Evm-Pdk Features
• USB-powered; no external power supply is required • Support for full ±15-A input current range and 36-V common-mode voltage range of the INA260 • EVM includes placeholders for transient voltage suppression (TVS) devices to protect the INA260 inputs from excessively high common-mode voltages •... -
Page 8: Related Documentation From Texas Instruments
EVM input terminals. The computer runs the GUI software through which the user can enable power to the INA260 and communicate with the device. User commands are sent through the computer's USB port to the SM-USB-DIG board that translates these commands into I C format, before sending them to the EVM. -
Page 9: Sm-Usb-Dig Platform Description
SM-USB-DIG Platform Description Figure 4 shows the block diagram for the SM-USB-DIG platform. This platform is a general-purpose data acquisition system that is used on several different Texas Instruments' evaluation modules. The details of operation are included in a separate document, SBOU098 (available for download at www.ti.com). -
Page 10: Ina260Evm Pcb Description
5V and 3.3V. The EVM supply voltage is user-selectable through the GUI. The 1µF ceramic capacitor, C2, placed in close proximity to the INA260 (U1) supply pin provides adequate decoupling to V for power supply rejection at higher frequencies. - Page 11 The V input of the INA260 is accessible through pin 2 of header J1. Pins 1 and 3 of J1 are connected to IN+ and IN–, respectively. Note that the V input is independent of the current input (that is, the V input can be applied with or without a load), and the INA260 provides an accurate voltage reading.
-
Page 12: Evm Digital Inputs And Outputs
C modes are supported. The outputs of the INA260 include SDA and ALERT, both of which are routed to J4 and are readable from the GUI. The GUI includes support for both over- and underlimit as well as conversion ready indicator modes of the ALERT pin. -
Page 13: One-Time Gui Software Installation
For the GUI text to be rendered correctly, the text size under Control Panel >> Appearance and Personalization >> Display (shown in Figure 6) must be set to Smaller - 100%. Figure 6. Recommended Display Settings SBOU180 – November 2016 INA260EVM-PDK and Software Tutorial Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated... -
Page 14: Ina260Evm Gui Installation
.zip file and run Setup_INA260EVM.exe. Follow the on-screen instructions provided in Figure 7 to complete the software installation. Figure 7. INA260EVM GUI Installation INA260EVM-PDK and Software Tutorial SBOU180 – November 2016 Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated... -
Page 15: Ina260Evm Jumper Settings
Ensure that the jumpers are installed in the correct positions, based on the required test conditions. Figure 8. INA260EVM Default Jumper Settings SBOU180 – November 2016 INA260EVM-PDK and Software Tutorial Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated... -
Page 16: Connecting The Hardware
Table 5. INA260EVM Test Board Jumper Functions Jumper Default Purpose This jumper selects whether the V pin on the INA260 is connected to the IN+ or IN– pin; see Section 2.2.2 for details. This jumper sets the A0 character of the 2-character I C device address;... -
Page 17: Sm-Usb-Dig Powers On When Connected To A Computer
SM-USB-DIG powers on, but the EVM does not. The power supply to the EVM must be enabled from the GUI. Figure 10. SM-USB-DIG Powers on When Connected to a Computer SBOU180 – November 2016 INA260EVM-PDK and Software Tutorial Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated... -
Page 18: System Power-Up
LED on the EVM immediately lights up, indicating that the EVM PCB is receiving power, as shown in Figure To input current source low side. Figure 11. INA260EVM Powers Up following the GUI Launch INA260EVM-PDK and Software Tutorial SBOU180 – November 2016 Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated... -
Page 19: Ina260Evm Gui Software
Figure Figure 12. V Selection With the INA260 powered on, the analog input sources can now be enabled. Section 4 discusses the GUI configuration and data collection using this setup. INA260EVM GUI Software The INA260EVM GUI is a collection of software tools that make it easy for the user to explore the key behaviors of the INA260. -
Page 20: Configuration Tool
INA260EVM GUI Software www.ti.com Configuration Tool The Configuration tool allows the user to modify the operating conditions of the INA260 as required. User- specified settings are translated to I C frames and written to the appropriate device registers whenever the user clicks the Write All Reg button. -
Page 21: Slave Address Setting
Therefore, step 1 involves selecting the correct A0 and A1 values that represent the slave address of the INA260 installed on the EVM. In other words, the states of A0 and A1 in the GUI must match the jumper settings chosen for J2 and J3 on the EVM. The equivalent hexadecimal value of the slave address is... -
Page 22: Configuring Conversion Times
INA260EVM GUI Software www.ti.com The Averaging Mode menu allows the user to select a desired number of samples for the INA260 averaging feature. This step configures the INA260 to compute and store the average value of the specified number of samples in the output register. The default value is 1. -
Page 23: Results Bar
18. The data displayed includes the states of the Alert and Conversion Ready flags. Results are updated every time the output registers of the INA260 are read by clicking the Read All Reg button. Alternatively, data can be read continuously by enabling the Continuously Poll Data button on the Graph tool page. -
Page 24: Registers Tool
20) allows the user to monitor and even change the contents of the internal user-accessible registers of the INA260 on a bit-by-bit basis. Bit names for the selected register are displayed on the lower panel of the page, but the user is advised to consult the INA260 datasheet detailed bit definitions that may be necessary when modifying the contents of the input registers. -
Page 25: Schematic
INA260EVM Documentation www.ti.com Schematic Figure 21 shows the schematic for the INA260EVM. Figure 21. INA260EVM Schematic SBOU180 – November 2016 INA260EVM-PDK and Software Tutorial Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated... -
Page 26: Pcb Layout
INA260EVM Documentation www.ti.com PCB Layout Figure 22 shows the component layout for the INA260EVM PCB. Figure 22. INA260EVM PCB Top Layer (Component Side) INA260EVM-PDK and Software Tutorial SBOU180 – November 2016 Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated... -
Page 27: Bill Of Materials
