4.3 Running Scripts

Scripts can be run by either of the following options:
1. Select Scripts -> Project Name e.g. ADV7611
2. Follow the script tree as outlined in the expanding menus (see Figure 5)
1. Select Scripts -> Run Script
2. Open the script folder of the desired project
3. Select the desired script and click "Open"
Please be patient as the script may take several seconds to run. Successful download of the script is
notified by the green light at the bottom of the screen flashing twice.
Figure 5 - XRC Script Tree
