- Page 1 ADV7281-M Installation Guide Rev. A March 2013...
-
Page 2: Table Of Contents
Description of the ADV7281-M Evaluation Board ....................4 Setting Up the ADV7281-M Evaluation Board ...................... 6 Download and Install an FTP Client ........................... 6 2.1. Download ADV7281-M Files From ADI FTP Site ....................6 2.2. Install the DVP Eval Program ............................7 2.3. -
Page 3: Introduction To The Adv7281-M Installation Guide
The content of this document is believed to be correct. If any errors are found within this document, or if clarification is needed, contact the local FAE. TRADEMARK AND SERVICE MARK NOTICE The Analog Devices logo is a registered trademark of Analog Devices, Inc. All other brand and product names are trademarks or service marks of their respective owners. Rev. A, March 2013... -
Page 4: Description Of The Adv7281-M Evaluation Board
ADV7281-M video decoder which converts it into a MIPI CSI-2 output stream. The MIPI CSI-2 output of the ADV7281-M consists of one differential data lane (D0+ and D0-) and one differential clock lane (Clk+ and CLk-). These are output to the SMA connectors on the evaluation board. -
Page 5: Figure 1. Adv7281-M Evaluation Board
LED D7: SMA connector Indicates USB connection is ok Ain1: Single-ended analog input Ain5 and 6: Ain3 and 4: Ain2: Differential Differential analog inputs Single-ended analog inputs analog input Figure 1. ADV7281-M Evaluation Board Rev. A, March 2013... -
Page 6: Setting Up The Adv7281-M Evaluation Board
2. SETTING UP THE ADV7281-M EVALUATION BOARD The Analog Devices (ADI) DVP Eval program and ADV7281-M script files are needed to operate the ADV7281-M evaluation board. The DVP Eval program and ADV7281-M script files are available on an ADI File Transfer Protocol (FTP) site. -
Page 7: Install The Dvp Eval Program
FTP site to your computer Figure 2. Image of ADI ADV7281-M FTP Site On the Local Site Pane, navigate to where you want to drop the ADV7281-M files. On the Remote Site Pane, select the ADV7281-M folder. Note: Do not select the ADV7281-MA folder. -
Page 8: Load The Adv7281-M Script Files
C:\Documents and Settings\USER_NAME\My Documents\Analog Devices\DVP Eval Latest Source 10-14-11\xml\New Boards. Note: This directory may be slightly different depending on where you installed the DVP Eval program. To open the DVP Eval program, select Start -> Analog Devices -> DVP Eval Latest Source 10-14-11. Select File -> Update Boards. -
Page 9: Power Up The Adv7281-M Evaluation Board
ADV7281-M script files. This cable is used to send commands from your computer to the ADV7281-M evaluation board. Connect the other end of the USB cable to Jumper J7 of the ADV7281-M evaluation board. When this is done correctly, LED D7... -
Page 10: Figure 6. Dvp Eval Program After Loading Adv7281-M Board
This is expected as the I C slave address of the CSI_Top map has not yet been programmed. This warning will disappear after any script is run (see step 7). Figure 7. Warning Message That Appears After Loading ADV7281-M Board Rev. A, March 2013... -
Page 11: Figure 8. Running Adv7281-M Script On Dvp Eval Program
ADV7281-M Installation Guide Select Scripts-> ADV7281-MCUST to select the script you wish to run (refer to Figure Figure 8. Running ADV7281-M Script on DVP Eval Program Rev. A, March 2013... -
Page 12: List Of Figures
Figure 7. Warning Message That Appears After Loading ADV7281-M Board ....................... 10 Figure 8. Running ADV7281-M Script on DVP Eval Program ..........................11 LIST OF TABLES Table 1. Acceptable Analog Video Input Formats to ADV7281-M Evaluation Board ..................... 4 REVISION HISTORY March 2013 – Rev. A Initial version.
