Before connecting the AV Receiver
Before connecting the AV Receiver, connect the cable/DSL modem,
broadband router and PC according to the figure on the right, and make sure
that you can browse Web pages through your broadband connection.
Note:
• Some cable/DSL modems incorporate the broadband router function.
• Set to "On" the DHCP function on the broadband router (Usually, the
DHCP function is set to "On" by default).
• For details on settings, refer to individual manuals for the PC, cable/DSL
modem, and broadband router. And also refer to the Net Audio pages in
the AV receiver's instruction manual.
Receiving the Internet radio
1. Connect the AV Receiver to the broadband router through Ethernet cable (See the figure above).
2. Press the NET A button on the remote controller to select the Internet Radio mode.
3. Press the DISPLAY button on the remote controller.
4. Use the / button to select your favorite mode.
5. Press the ENTER button to confirm your selection.
6. Repeat steps 4 and 5 to select your favorite radio station as required.
"Buffering" appears in the display. After the buffering status comes to "100%," playback of the station starts.
Note:
• Depending on network environment, selecting an Internet radio station and starting playback may take longer.
• For settings on Internet Radio, refer to the Net Audio pages in the AV receiver's instruction manual.
• If your network is configured with proxy server, the settings on proxy server will be required. In such case, contact your
network administrator (Refer to the Proxy Setup section on the Net Audio pages in the AV receiver's instruction manual).
Setting up the PC and Net-Tune server
1. Make sure that you can browse Web pages through Internet
connection according to the instructions of "Before
connecting the AV Receiver" above.
2. Download the Net-Tune Central music server software from
ONKYO Web site (http://www.onkyousa.com/net-tune/).
On the download page, you are required to enter the product
serial number written on the rear panel of the unit. Before setting
up the product, be sure to write down the product serial number.
3. Execute SETUP.EXE contained in the downloaded file to
install the Net-Tune Central software.
Playing the music stored on the Net-Tune server
1. Start Net-Tune Central on your PC.
2. Turn on the AV Receiver.
3. Press the NET A button on the remote controller.
4. Press the button on the remote controller to play the music file.
SN 29343595
Net Audio Quick Setup Guide
AV Receiver
Internet
ETHERNET
(Net -Tune)
To the WAN
side
Modem
Router
PC
LAN port/
Ethernet, etc.
To the LAN
side port
To the LAN
side port
