- Page 1 BEYOND IMAGINATION HOME THEATER TX - NR5000E & DV - SP1000E...
-
Page 2: Home Theater
The next ONKYO innovation to rock the home cinema industry was the world’s first 7.1 channel home cinema receiver, the TX - DS989. At the same time as this momentous event, ONKYO released its first THX certified DVD player, the DV - S939. - Page 3 THX ULTRA2 7.1 CHANNEL A/V NETWORK RECEIVER Welcome to the full potential of what a home cinema receiver can be. ONKYO, the company that brought you the world’s first 7.1 channel and THX certified receiver now unveils the new definition of flagship receiver. The TX-NR5000E provides technology and design that will impress all, from the audiophile to the casual listener.
- Page 4 TX - NR5000E THE WORLD WILL BE AT ITS FEET www.eu.onkyo.com...
- Page 6 MULTI-ROOM CAPABILITY Bi-Directional RS232 Terminal Colour-Coded Heavy Duty Dual Banana Plug Since this is too good to keep in just one room, the TX-NR5000E Compatible Transparent Speaker Posts also gives you the capability to enjoy your movies or music Colour-Coded 7.1 Multi-Channel Inputs and Pre Outs TX - NR5000E EXCEPTIONAL QUALITY INSIDE –...
- Page 7 Solid Aluminium Volume Knob for quality you can feel–ergonomically pleasing and convenient for those quick in-the-dark level changes Rec Out Selector (On Front) to tape one program while watching or listening to another Massive Shielded-Toroidal Transformer the kind you find only in the highest-end audio equipment, to provide copious amounts of pure current 2 High-Bandwidth HDMI Inputs and 1 Output for the transmission of the highest-quality...
- Page 8 THE NEW BENCHMARK IN AUDIO ENGINEERING A truly great home cinema receiver will sport a design and features that set it apart from the rest. The TX-NR5000E earns its place at the top with a unique modular design on the rear panel featuring a vast array of the latest digital and analogue inputs and outputs.
- Page 9 Module E MULTI-CHANNEL INPUTS 2 sets of multi-channel inputs for DVD-Audio or Super Audio CD analogue sources Module F AUDIO A INPUTS AND OUTPUTS Analogue sources are not for- gotten with an array of inputs and outputs including a phono input for vinyl fans Module G AUDIO B INPUTS AND...
- Page 10 OVER 50 YEARS OF ENGINEERING ACCLAIM IS JUST THE STARTING POINT ONKYO challenged its engineers to do the seemingly impossible, reinvent the flagship receiver concept–and don’t leave anything out. The result is the merging of science and design that represents our greatest technological accomplishment.
-
Page 11: Pure Audio Mode
Though this design is more expensive and difficult to implement, we think it’s an ONKYO design difference you’ll hear, and a shortcut you’ll be glad we didn’t take. PURE AUDIO MODE... - Page 12 Aluminium Volume Knob DIGITAL UPSAMPLING The TX-NR5000E can take a 48 kHz digital signal and double its sampling frequency to 96 kHz, to glean nearly twice as much signal information–which means greater detail and clarity from all your regular CDs and two-channel analogue sources.
- Page 13 WITNESS THE NEXT GENERATION OF USER INTERFACE While the size and features of the TX-NR5000E may be ominous, the user interface will calm the fears of even the most technophobe of us. Simple and ergonomically designed, the onscreen menus, technologically advanced yet easy-to-use remote control and features may sound intimidating but in reality are more convenient than ever before.
- Page 14 TX - NR5000E RS232 PORT The TX-NR5000E is ready to grow with you. Let’s face it, this receiver is an investment and you wouldn’t want it to become obsolete anytime soon. The bi-directional RS232 port and software upgradable capability of this receiver means that you’re ready for those decoding...
- Page 15 DSP modes, that are simply on the spec sheet in a feeble attempt to be more competitive on the sales floor. Enter ONKYO DSP. Our engineers, many of whom are trained musicians, dedicat- ed themselves to one audio objective: psycho-acoustically accurate, natural effects that match the music source.
-
Page 16: Dolby Headphone
Not enough? Well we’re not stopping there. An LCD screen and scroll wheel let you find the component you wish to control–a DVD player, receiver, video recorder, what- ever–with just a spin. And when you want direct access to your TV, buttons at the top let you control the channel and volume without hunting around. - Page 17 HDMI (High-Definition Multimedia Interface) and i.LINK (a. k. a. IEEE 1394) connections for high-quality movies and multi-channel music. ONKYO’s VLSC (Vector Linear Shaping Circuitry) and FlexScale from Oplus video scalling of 480i to 480p/720p or 1080i guarantee superlative audio and video playback that other manufacturers can’t match.You’ll find all of this contained within a THX Ultra certified component that’s ready to deliver a sensational standard of audio and video...
- Page 18 DV - SP1000E TOGETHER WITH THE TX - NR5000E, AN UNPARALLELED ALLIANCE OF AUDIO - VISUAL PERFECTION www.eu.onkyo.com...
- Page 20 HDMI (High-Definition Multimedia Interface) An HDMI output provides you with the highest bandwidth audio and video from a single cable www.eu.onkyo.com VIDEO OUT BOARD Holds the high quality 216 MHz/14-bit NSV video DAC from Analog Devices for crystal- clear video...
- Page 21 DIGITAL AND ANALOGUE AUDIO BOARD Analogue still sounds marvellous with this high-precision board to connect external decoders for DVD-Audio and Super Audio CD for professional-grade, unaltered, wide-bandwidth video-signal transfer ANALOGUE AUDIO DRIVER BOARD High-precision integrated circuits handle such essential tasks as digital-to-analogue conversions with ease High-Power Transformer This high-power transformer is part of the reason–the...
- Page 22 NSV VIDEO DAC A crucial factor in achieving clear, pristine digital video playback is the video D/A converter in your DVD player. The state-of-the- art 216 MHz/14-bit video DAC from Analog Devices featured in the DV-SP1000E gives you the finest artifact-free picture available.
- Page 23 That’s why the DV-SP1000E can pass PLUGE (Picture Line Up Generation Equipment) signals, a test pattern that makes it easy to accurately calibrate the black-level of a monitor to the DVD player. 2 GOLD-PLATED S-VIDEO OUTPUTS To carry luminance and colour information in separate signal paths to TVs and monitors with- out component video inputs.
- Page 24 IT WOULD TAKE A METEOR TO WIPE THIS OUT Evolution of build qua- lity has truly peaked with this ONKYO player fea- turing an anti-re- sonant, heavy-gauge, reinforced-steel chassis...
- Page 25 DVD signal must be interlaced–a method where the picture is split into two fields and then “interlaced” back together to look like one. ONKYO’s exclusive Veridic Progressive Scan for NTSC and PAL systems, retrieves the original progressive signal, and on such compatible displays as HDTV, Plasma or digital TV and high-end pro- jectors, “paints”...
- Page 26 Due to a policy of continuous product improvement, ONKYO reserves the right to change specifications and appearance without notice. “THX” is a trademark or registered trademarks of THX Ltd. “Dolby”, “Pro Logic”...
-
Page 27: Home Theater
HOME THEATER PRODUCT SPECIFICATIONS Features TX - NR5000E – THX Ultra2 Network A/V Receiver AMPLIFIER DESIGN Identical Full-Bandwidth Channels Reduced NFB (Negative Feedback) Design WRAT (Wide Range Amplifier Technology) VLSC (Vector Linear Shaping Circuitry) Non-Scaling Configuration BTL (Bridge Tie Load) 192 kHz/24-Bit DACs Absolute Ground Plate High Current Low Impedance Drive... - Page 28 More information at your ONKYO dealer:...
