Address 60 and Address 61—RTCALR (RTC Countdown Alarm Timer Repeat Data Registers)
Table 57. Bus Assignment Bit Map for the RTCALR Registers
Data
Register Range
RTCALR_SEC 0 to 119
RTCALR_MIN 0 to 59
1
The read status is assigned to Bit 7 (see the I
Address 62—RTCALRMD (RTC Countdown Time Alarm Mode Register)
Table 58. Bus Assignment Bit Map for the RTCALRMD Registers
B7 (MSB) B6
RDST_ALRM 0
Address 97—SEL_FSW (Switcher Frequency Select Register)
Table 59. Bus Assignment Bit Map
B7 (MSB) B6
0 SEL_FREQ7
Table 60. SEL_FSW Programming Bits
Bits Description
SEL_FREQ7 Channel 7 switching frequency.
0: 1.25 MHz.
1: 2.5 MHz.
SEL_FREQ4 Channel 4 switching frequency.
0: 1.25 MHz.
1: 2.5 MHz.
SEL_FREQ3[1:0] Channel 3 switching frequency.
00: 1.25 MHz.
01: 625 kHz.
10: 312 kHz.
11: 2.5 MHz.
SEL_FREQ2 Channel 2 switching frequency.
0: 1.25 MHz.
1: 2.5 MHz.
SEL_FREQ1 Channel 1 switching frequency.
0: 1.25 MHz.
1: 2.5 MHz.
Address 98—VID_REGO (VID for VREGO Output Voltage)
Table 61. Bus Assignment Bit Map
B7 (MSB) B6
0 0
Table 62. VID_REGO Programming Bits
Bits Description
VID_REGO VREGO output voltage selection.
0: 3.2 V.
1: 3.0 V.
B7 (MSB) B6
RDST_RSEC RSEC_6
RDST_RMIN 0
2
C Interface section).
B5 B4
0 ALMMD
B5 B4
1 SEL_FREQ4
B5 B4
0 0
