Product description
3. Update the software and firmware of the terminal.
4. Export credit card transactions, etc.
Most of the functions available in the service mode can, however, be performed
more conveniently through the WebOffice Service.
The terminal exits the service mode when you close the door again. The printer
can produce a printout showing the software and firmware versions installed in
the terminal and data regarding the printer, including the current printer settings.
This lets you check any changes you have made while in the service mode. This
feature is default enabled but can be disabled.
Reference:
For a detailed description of the service menu see CWT Software Configuration
Handbook.
4.10

CWT S5 interconnections

This chapter aims to shows how each part of the terminal is connected to the
CPU board.
The drawings are available in a separate document available on our Partner Area

4.10.1 CPU board version 0501-E0153 Rev B

The CPU board consists of a main printed circuit board assembly. It contains a
32-bit 800 MHz processor with a 256 MB non-volatile flash memory used to store
the operating system (Windows EC7) and a 512 MB RAM. The real-time clock is
backed up by a battery positioned on the CPU board.
The figure below shows the positions of connectors etc. The figure is followed by
a list of all connectors and their use.
