The Coin detection sensor is mounted in the door and has 2 pins on the back
that will guide the coin validator to line-up with the coin detection sensor. it also
sports a lip (red arrow) that will push the coin validator in place when the door is
closed.
Figure 7, Coin detection sensor
Figure 8, Coin detection sensor
front
back
4.3.4.2 Coin validator
The coin validator reveals if valid coins have been used. The validator also
includes sophisticated electronics for determining what type of coin is passing.
Figure 9, Coin validator
