Anybus
Wireless Bridge II CAN

Use Cases

7. Use Cases

7.1. Bridge II CAN Point-to-Point Installation

CAN cable replacement is enabled by using two pieces of Bridge II CAN which creates a wireless bridge for the
CAN communication.
Figure 36. Bridge II CAN Point-to-Point Installation
Page 50 of 72
SCM-1202-184 2.0
