Anybus Wireless Bridge II CAN
To add additional units
When using Easy Config Mode 5 or 6, up to seven additional Units can be added.
NOTE
When using Easy Config mode 4, the next unit to be added must be set up within 120 seconds after
the first unit was restarted.
• To add a Unit, repeat the configuration steps, see
Each new Client unit will be assigned the next free IP address in the current Ethernet subnet.
Verify operation
See LED Indicators (page 47).
• On Units configured with Bluetooth, verify that the BT LED is lit.
• On Units configured with Easy Config Mode 4, the A-B-C-D LED lights indicates the Bluetooth link quality.
• On Units configured with WLAN, verify that the WLAN LED is lit.
To configure additional settings
• To configure additional settings, log in to the built-in web interface for each unit you want to configure.
See Configure Settings in the Built-In Web Interface (page 29)
Page 22 of 72
Configuration steps (page 20).
Configuration with Easy Config
SCM-1202-184 2.0
