Surface Mounting
4.2. Surface Mounting
Bridge II CAN can be screw-mounted directly onto a flat surface.
Before You Begin
NOTE
To avoid signal interference, a minimum distance of 50 cm between the devices should be observed.
See also
Wireless Technology Basics (page
Procedure
Figure 3. Surface mounting holes
•
To screw-mount the Bridge II CAN on a surface, use the two holes (Ø 4 mm) at the corners of the Bridge II
CAN.
SCM-1202-184 2.0
64).
®
™
Anybus
Wireless Bridge II CAN
Page 7 of 72
