Open-Q™ 660 HDK Hardware Development Kit based on the Snapdragon™ 660 processor User Guide Version 1.0

3. OPEN-Q 660 HARDWARE DEVELOPMENT KIT

3.1 Introduction

The Open-Q 660 Hardware Development Kit provides a quick reference or evaluation platform
for Qualcomm's Snapdragon
developers, OEMs, consumer manufacturers, hardware component vendors, video
surveillance, robotics, camera vendors, and flash chip vendors to evaluate, optimize, test and
deploy applications that can utilize the Qualcomm® Snapdragon™ 660 series technology.

3.2 Development Platform Notice

This development platform contains RF/digital hardware and software intended for engineering
development, engineering evaluation, or demonstration purposes only and is meant for use in
a controlled environment. This device is not being placed on the market, leased or sold for use
in a residential environment or for use by the general public as an end user device.
This development platform is not intended to meet the requirements of a commercially available
consumer device including those requirements specified in the European Union directives
applicable for Radio devices being placed on the market, FCC equipment authorization rules
or other regulations pertaining to consumer devices being placed on the market for use by the
general public.
This development platform may only be used in a controlled user environment where operators
have obtained the necessary regulatory approvals for experimentation using a radio device and
have appropriate technical training. The device may not be used by members of the general
population or other individuals that have not been instructed on methods for conducting
controlled experiments and taking necessary precautions for preventing harmful interference
and minimizing RF exposure risks. Additional RF exposure information can be found on the
FCC website at http://www.fcc.gov/oet/rfsafety/

3.3 Anti-Static Handling Procedures

The Open-Q 660 Hardware Development Kit has exposed electronics and chipsets. Proper
anti-static precautions should be employed when handling the kit, including but not limited to:
• Using a grounded anti-static mat
• Using a grounded wrist or foot strap

3.4 Kit Contents

The Open-Q 660 Hardware Development Kit includes the following:
o Open-Q 660 Processor board with the Snapdragon
main CPU board
o Mini-ITX form-factor carrier board for I/O and connecting with external peripherals
o 12V power adapter
o USB type-C cable and charger
660 processor. This kit is suited for Android / Linux application
™
9
Copyright Intrinsyc Technologies Corporation
660 (SDA660) processor
™
