Open-Q™ 660 HDK Hardware Development Kit based on the Snapdragon™ 660 processor User Guide Version 1.0
GNSS Antenna
LED
LCD Display and Touch
connector
Sensor header
SIM Card
CSI Camera connectors
The sections below will provide in depth information on each expansion header and connector
on the carrier board. The information listed below is of particular use for those who want to
interface other external hardware devices with the Open-Q 660 Processor board. Before
connecting anything to the development kit, please ensure the device meets the specific
hardware requirements of the processor.

3.8.2.1 Power Options

The Open-Q 660 Hardware Development Kit power source connects to the 12V DC power
supply jack J0701. Starting from the power jack, the 12V power supply branches off into
PCB Antenna
3xLED
100 pin for LCD signals
from B2B boards for display
24 pin sensor header
WWAN SIM card connector
(optional)
3 x CSI port connector with
CLK, GPIOS, CCI
Copyright Intrinsyc Technologies Corporation
GNSS :
1574.42 MHz – 1576.42
MHz
GLONASS :
1587 MHz – 1606 MHz
COMPASS: 1559.05 to
1563.14MHz
Galilei: 4.092MHz
BW(centered on
1575.42MHz)
Red : PMIC Driven
Green: PMIC Driven
Blue: PMIC Driven
4-lane MIPI DSI0 , DSI1
I2C/SPI/GPIO
Backlight
MIPI Alliance Specification
v1.2
MIPI D-PHY Specification
v0.65,v0.81, v0.90, v1.01,
V1.2
MIPI C-PHY Specification
v1.0
24 pin sensor header
4bit Micro SIM card support
Supports 3 x Camera
interfaces via three
separate connectors
▪ 3 x MIPI-CSI each 4 lane
▪ External flash driver
control
▪ Support for 3D camera
configuration
▪ Separate I2C / CCI
control
MIPI Alliance Specification
v1.2 for Camera Serial
Interface
21
Antenna to Carrier board
Red : General purpose
Green : General purpose
Blue : General purpose
Can work as one dual DSI
or both independent display
Header to connect sensor
board.
For WWAN mini PCI
express cards (for internal
use only – not supported)
See Note: 36
