2.3 Setting up the Paging Server

Before you set up the Paging Server, be sure that you have received all the parts described in
2.1, "Parts

2.3.1 Connect to the Power Source

To use PoE, plug a Cat 5 Ethernet cable from the Paging Server Ethernet port to your network. As an
alternative to PoE, you can plug one end of a +48V DC power supply into the Paging Server, and
plug the other end into a receptacle. If required, connect the earth grounding wire to the chassis
ground on the back of the unit.

2.3.2 Connect to the Network

Plug one end of a standard Ethernet cable into the Paging Server Ethernet port. Plug the other end
into your network.
VoIP Paging Server Operations Guide
List".
Figure 2-2. Connecting to the Power Source
48V DC
Figure 2-3. Connecting to the Network
930132F
Implementing the VoIP Paging Server
Chassis
ground
48V DC
Setting up the Paging Server
Section
CyberData Corporation
5
