Maintenance and Service
12.2 Removing and installing hardware components
Steps for removing the hard disk
3.
4.
5.
Installing hard disk
To install a hard disk, perform the actions described in "Removing the hard disk" in the
reverse order.
106
Remove the four screws which secure the
hard disk to the computer housing. Remove
the hard disk bracket including hard disk
from the computer housing.
Remove two screws at the front and rear to
remove the hard disk from the hard disk
bracket.
Carefully pull the hard disk out of the hard
disk bracket.
