Mounting of tools on the side of an LC3 IC

A
It is possible to mount tools on all 4 sides of the LC3 IC at the same time� However, it requires that the
holes for mounting are placed with different distances from the top and/or bottom plate� Otherwise the
mounting screws will collide�
Minimum distance from the top and bottom plate must be observed�
3-stage
C
(M4) 142 -146
(M5) 143 -146
(M6) 144 -146
(M8) 146
C
Screws used for mounting of a product on the side of the LC3 IC must be 8�8�
Pamir Hamid
Screw type
Screw torque Nm
Note: There is no installed grounding cable connecting the top and bottomplate�
15
30
2022-07-07
M8 M6 M5
2022-07-11
17 7 4
SECTION A-A
B-B
Drill-Max. 12
Thread-Max 10
Drill-Max. 13
Thread-Max 11
Drill-Max. 15
Thread-Max 13
Drill-Max. 16
Thread-Max 14
SECTION C-C
M4
2
Lifting Column LC3 IC | 28
43
30
B
