DL2 and CBD6S system
User manual
LINAK.COM/DESKLINE
Page 1 of 23

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DESKLINE DL2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Linak DESKLINE DL2

  • Page 1 DL2 and CBD6S system User manual LINAK.COM/DESKLINE Page 1 of 23...
  • Page 2: Table Of Contents

    Bending moment ........................... 14 Installation of CBD6S (SMPS) ...................... 15 Electric connection of the DL2 with control box ..............16 Initialising DL2 systems ........................ 17 Disposal of LINAK’s products ...................... 18 Labels ............................19 Drawing appendix .......................... 20 Addresses ............................23...
  • Page 3: Preface

    This User Manual does not address the end-user. It is intended as a source of information for the manufacturer of the equipment or system only, and it will tell you how to install, use and maintain your LINAK electronics. It is the responsibility of the manufacturer of the end-use product to provide a User Manual where relevant safety information from this manual is passed on to the end-user.
  • Page 4: Valid For

    Valid for: This User Manual is valid for the following products: (See the first 3 - 5 characters on the label) Lifting columns: Control boxes: CBD6S 200 W, CBD6S 300 W Controls: DP1U/DPF1M (if memory function is required) DP1C/DPT/DPF1C (if memory function and display is required) or DPA/DPB/DPH/DP1K/DP1V/DPF1K (if only up/down is required.) Page 4 of 23...
  • Page 5: Important Information

    Important information Important information on LINAK products can be found under the following ® headings: Warning! Failure to comply with these instructions may result in accidents involving serious personal injury. Failing to follow these instructions can result in the product being damaged or being destroyed.
  • Page 6: Before Installation, Reinstallation Or Troubleshooting

    • System connection. The individual parts must be connected before the control box is connected to the mains. See the User Manual for LINAK actuators, if necessary. During operation: • If the control box makes unusual noises or smells, switch off the mains voltage immediately.
  • Page 7: Only For Eu Markets

    Only for EU markets This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
  • Page 8: Repairs

    Products under warranty must also be returned to authorised LINAK service centres. Further information on DESKLINE warranty can be found on the LINAK website www.linak.com/warranty. Warning! If any of the DESKLINE products are opened, there will be a risk of subsequent malfunction.
  • Page 9: Declaration Of Conformity

    Authorized to compile the relevant technical documentation Original Declaration RoHS compliance If required, the RoHS mark must be obtained by the manufacturer of the end products. LINAK A/S can supply the required material information on our products. For more information, visit: https://www.linak.com/about/declarations/ or contact: chemicalcompliance@linak.com...
  • Page 10: Misc. On The Deskline ® System

    ® Warranty This DESKLINE product is subject to warranty pursuant to the terms of LINAK DESKLINE Warranty Paper, available on the LINAK website www.linak.com/warranty. Maintenance Clean dust and dirt on the outside of the system at appropriate intervals and inspect them for damage and breaks.
  • Page 11: Etl-Markering

    ETL-marking Due to space limitations, the complete ETL-marking demands are not represented on the marking plates. The full ETL Recognized Component markings are shown here. C/N 120690 Conforms to UL962 Cert. to CSA Std. C22.2 No. 68-09 ETL Recognized Component mark for Canada and United States C/N 9901916 Conforms to UL962...
  • Page 12: Description Of The Deskline ® System

    Description of the DESKLINE system ® Each DESKLINE actuator/column is equipped with a motor and parallel/memory drive is ensured by means of software in the ® CBD6S that also takes account of an uneven load on the desk. Soft start and stop are also part of this software, which ensures a soft start and stop when adjusting the desk.
  • Page 13: Mounting Guidelines For Dl2

    Mounting guidelines for DL2 The DL2 column is supplied with either 8 mm end plates or 3 mm end plates. 8 mm end plates: For mounting on the desk frame there are 4 holes for M10 bolts. It is recommended to use all 4 bolts. 3 mm end plates: For mounting on the desk frame there are 4 holes in the column for DG 80x35 screws.
  • Page 14: Bending Moment

    The spindle part is placed in the same side as the cable outlet. See the DL2 data sheet for further information regarding bending moment. LINAK recommends that the DESKLINE system should be used in push applications.
  • Page 15: Installation Of Cbd6S (Smps)

    Installation of CBD6S (SMPS) Do not pack the CBD6S in heat insulating material. Place the CBD6S so it can emit heat through its surface to the surroundings. Mounting the CBD6S 1. Plug the mains cable into the CBD6S. 2. Place the mains cable in the groove for cable relief. 3.
  • Page 16: Electric Connection Of The Dl2 With Control Box

    Electric connection of the DL2 with control box The control box must only be connected to the voltage stated on the label. It is important to ensure that the motor cables are fixed, but not tightened, near the control box and near the columns. Fix the cable to the tabletop using a clip observing the 30 mm minimum bending radius (R).
  • Page 17: Initialising Dl2 Systems

    Initialising DL2 systems Downward direction 1. Press the desk panel to drive the desk down. Keep pressing the desk panel. 2. Release the desk panel when the movement stops. The system is now initialised in downward direction. Upward direction The first two times the system moves into end stop in upward direction, the system runs approximately 3 mm back to initialise in upward direction.
  • Page 18: Disposal Of Linak's Products

    Disposal of LINAK products As LINAK customers often ask us how our products can be disposed of or scrapped we have prepared this guidance that enables a classification to different waste fractions for recycling or combustion. Guidance We recommend that our products be disassembled as much as possible and divided into different waste groups for recycling or combustion.
  • Page 19: Labels

    4 channels LINAK APPLICATION POLICY The purpose of the application policy is to define areas of responsibilities in relation to applying a LINAK product defined as hardware, software, technical advice, etc. related to an existing or a new customer application.
  • Page 20: Drawing Appendix

    DRAWING APPENDIX DL2 Lifting Column Page 20 of 23...
  • Page 21 CBD6S 200 W (SMPS) Page 21 of 23...
  • Page 22 CBD6S 300 W (SMPS) up to 4 channels Page 22 of 23...
  • Page 23: Addresses

    ® without prior notice. LINAK cannot guarantee product availability and reserves the right to discontinue the sale of any product. The user is responsible for determining the suitability of LINAK products for a specific application. All sales are subject to the ‘Standard Terms of Sale and Delivery’, available on LINAK websites.
