Connection diagram ELEVATE Pro

The speed control over the analogue 4-20 mA is started when the signal is set between 11-13 mA for 100
ms�
After this initialization the full signal width can be used to control the speed (see graphic below)�
In case the analogue signal exceeds 19,5 mA or the signal falls below 4,5 mA, the column will stop and go
into an error mode�
This error can be cleared by repeating the initialization sequence, meaning the signal must be set between
11-13 mA for 100 ms�
Stop
Extending at full speed
100% speed
Extend
25% speed
Stop
25% speed
Retract
100% speed
Retracting at full speed
Stop
Lifting Column LC3 IC | 22
95% 19,5 mA
90% 19 mA
55% 13 mA
45% 11 mA
10% 5 mA
5% 4,5 mA
