Drawing No.: TEC-0001888

Built-in dimensions

101 0.5
The minimum built-in dimension (BID) is 480 mm due to the design of the lifting column�
A
The tolerance for BID is +/- 1�5 mm

LC3 IC mounting guidelines

LC3 IC is for use in push applications and can be mounted in both directions – largest profile down or
largest profile up� The column can only be used for vertical movement -not for horizontal�
Top plate up
A
C
(M4) 142 -146
Note: The cable outlet for motor connection is positioned at the top (smallest profile)
(M5) 143 -146
Mount the LC3 IC in the application using the 4x M10 mounting holes in both endplates�
If the column is to be used with a constant high off-center load, we recommend to install the constant
(M6) 144 -146
weight in one of the 3 ways illustrated by the green symbols� It is not recommended to install the weight on
the opposite side of the mechanical endstop as illustrated with the red symbol� This installation can create an
(M8) 146
uneven movement and noise when the lifting column reaches the endstop position�
C
Created By Pamir Hamid
Modified By Pamir Hamid
REP = STANDARD-SBU
M10x1.5
15
30
Thread-Max 10
Thread-Max 11
Thread-Max 13
Thread-Max 14
2022-07-07
2022-07-11
½ S + 280mm
43 0.5
Top plate down
SECTION A-A
B-B
Drill-Max. 12
Drill-Max. 13
Drill-Max. 15
Drill-Max. 16
SECTION C-C
SCALE : 1:5
Lifting Column LC3 IC | 10
M10x1.5
146 0.5
B
43
B
30
