Use 4 pcs� M10 8�8 bolts at each end of the column for mounting to the application�
The screw depth must be min� 20 mm and max� 30 mm in the aluminum profile�
Screw torque: 35 Nm�
A
A
15 mm distance to thread
½ S + 280mm
101 0.5
C
(M4) 142 -146
(M5) 143 -146
(M6) 144 -146
(M8) 146
• It is recommended to use bolts with thread-lock adhesive
• Bolts of high quality steel 8�8 or 10�9 must be used to secure safe mounting of the LC3 IC to the
C
application�
Pamir Hamid
SECTION A-A
15
30
Bolt depth min. 20 mm
Mounting holes
M10x1.5
43 0.5
Drill-Max. 12
Thread-Max 10
Drill-Max. 13
Thread-Max 11
Drill-Max. 15
Thread-Max 13
Drill-Max. 16
Thread-Max 14
SECTION C-C
A
2022-07-07
2022-07-11
15
A
30
REP = STANDARD-SBU
SECTION A-A
B-B
M10x1.5
43
30
Lifting Column LC3 IC | 12
B
SCALE : 1:5
43
B
30
43 mm distance to thread
½ S + 280mm
146 0.5 43 0.5
B
B
SECTION A-A
