DEMO MANUAL DC2630A

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 8 C1, C2, C7, C8, C11, C12, C15, C16
2 8 C4, C5, C9, C10, C13, C14, C17, C18 CAP ., X7R, 2.2µF, 100V, 10% 1206
3 1 C6
4 1 C24
5 4 D1, D3, D5, D7
6 4 L1, L2, L3, L4
7 4 R3, R16, R22, R26
8 4 R4, R17, R23, R27
9 4 R5, R18, R24, R28
10 1 R30
11 1 U1
Additional Demo Board Components
1 1 C3
2 0 C20–C23(OPT)
3 4 M1, M2, M3, M4
4 1 R1
5 1 R2
6 0 R6, R7, R12, R13, R14, R15, R19,
R20, R21, R25, R31, R33, R34
7 5 R8, R9, R10, R11, R29
Hardware: For Demo Board Only
1 8 E3, E4, E8, E11, E16, E17, E18, E20
2 13 E1, E2, E5, E6, E7, E9, E10, E12, E13,
E14, E15, E19, E21
3 2 JP1, JP2
4 2 XJP1 ,XJP2
5 1 J1
6 2 J2, J3
7 4 MH1–MH4
6
PART DESCRIPTION
CAP ., X7R, 2.2µF, 50V, 10% 1206
CAP ., X5R, 4.7µF, 16V, 10% 0603
CAP ., X7R, 1.0µF, 50V, 10% 0603
SCHOTTKY DIODES, PMEG6010CEH, SOD-123
IND., 10µH
RES., 2Ω, 1/2W, 1% 1206
RES., 1M, 1/10W, 1% 0603
RES., 22.6k, 1/10W, 1% 0603
RES., 47.5k, 1/10W, 1% 0603
IC., LT3966, QFN-40, 6mm × 6mm
CAP ., ALUM., 47µF, 50V, 6.3×7.7 SIZE
CAP ., OPTION, 0603
P-MOSFET, 60V, SOT-23
RES., 84.5k, 1/10W, 1% 0603
RES., 499k, 1/10W, 1% 0603
RES., OPTION, 0603
RES., 100k, 1/10W, 1% 0603
TESTPOINT, TURRET, .094" PBF
TESTPOINT, TURRET, .061" PBF
HEADER 3-PIN 0.079 DOUBLE ROW
SHUNT, .079" CENTER
HEADER, 2×7 DUAL ROW
JACK BANANA
STAND-OFF , NYLON 6.4mm
MANUFACTURER/PART NUMBER
AVX, 12065C225KAT2A
AVX, 12061C225KAT4A
MURATA, GRM188R61C475KAAJD
TAIYO YUDEN, UMK107AB7105KA-T
NXP , PMEG6010CEH
WURTH ELEKTRONIK, 74438336100
SUSUMU, RL1632R-2R00-F
VISHAY, CRCW06031M00FKEA
VISHAY, CRCW060322K6FKEA
VISHAY, CRCW060347K5FKEA
ANALOG DEVICES., LT3966EUJ#PBF
WURTH ELEKTRONIK, 865080645012
VISHAY, Si2309CDS-T1-GE3
VISHAY, CRCW060384K5FKEA
VISHAY, CRCW0603499KFKEA
VISHAY, CRCW0603100KFKEA
MILL-MAX, 2501-2-00-80-00-00-07-0
MILL-MAX, 2308-2-00-80-00-00-07-0
WURTH ELEKTRONIK, 62000621121
WURTH ELEKTRONIK, 60800213421
MOLEX, 87831-1420
KEYSTONE, 575-4
WURTH ELEKTRONIK, 702931000
Rev. 0
