QUICK START PROCEDURE
4. Download the Linduino code and library files from
the DC2630A web page.
5. Upload the code to the connected Linduino
demo circuit.
6. With power off, connect a string of up to 16 LEDs
between each channel's LED
Connect the EN/UVLO turret to GND to keep the cir-
cuit shut down. With the power off, connect the input
power supply to the V
+
and GND turrets.
and GND terminals.
IN
Figure 1. Test Setup Drawing for DC2630A
DEMO MANUAL DC2630A
2
7. For I C serial communications, set JP1 (ADDR1)
to 1 and JP2 (ADDR2) to 1. This is the chosen I
address for the DC2630A command line interface.
8. Open up the serial monitor inside Arduino IDE.
9. Turn on 12V power to the V
the DC2630A.
10. Use command line interface in serial monitor to eval-
uate the performance of the LT3966 demo circuit.
2
C
and GND pins of
IN
