Figure 2.5: SRAM Lithium Battery Location

2.10.2 Jumper Setting for SRAM

You could set up SRAM enable or diable by jumper CN44.
SRAM Enable/Disable Jumper Setting (CN44)
Status Function
Open Enable SRAM function (Default)
Closed Disable SRAM function
15 Chapter 2
