- Page 1 User Manual UNO-3483G Series Intel® Core® i7 Processors Embedded Automation PC, with 1x PCI(e) Extension Slots...
- Page 2 限用物質含有情況標示聲明書 UNO-3483G 系列 設備名稱： 型號 （型式） ： 電腦 Equipment name Type designation (Type) ( 系列型號參見說明書 ) 限用物質及其化學符號 Restricted substances and its chemical symbols 六價鉻 多溴聯苯 多溴二苯醚 單元 Unit 汞 鎘 Hexavalent Polybrominated Polybrominated 鉛 Lead Mercury Cadmium chromium biphenyls diphenyl ethers (Pb) (Hg) (Cd)
- Page 3 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
- Page 4 Because of Advantech’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Advantech product is defec- tive, it will be repaired or replaced at no charge during the warranty period. For out- of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
- Page 5 Technical Support and Assistance Visit the Advantech web site at http://support.advantech.com where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information ready before you call: –...
- Page 6 The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
- Page 7 安全指示 請仔細閱讀此安全操作說明。 請妥善保存此用戶手冊供日後參考。 用濕抹布清洗設備前，請從插座拔下電源線。請不要使用液體或去汙噴霧劑清洗 設備。 對於使用電源線的設備，設備周圍必須有容易接觸到的電源插座。 請不要在潮濕環境中使用設備。 請在安裝前確保設備放置在可靠的平面上，意外跌落可能會導致設備損壞。 設備外殼的開口是用於空氣對流，從而防止設備過熱。請勿覆蓋開孔。 當您連接設備到電源插座上前，請確認電源插座的電壓是否符合要求。 請將電源線佈置在人們不易絆到的位置，並不要在電源線上覆蓋任何雜物。 請注意設備上的所有警告和注意標語。 如果長時間不使用設備，請將其同電源插座斷開，避免設備被超標的電壓波動損 壞。 請不要讓任何液體流入通風口，以免引起火災或者短路。 請不要自行打開設備。為了確保您的安全，請由經過認證的工程師來打開設備。 如遇下列情況，請由專業人員來維修： 電源線或者插頭損壞； 設備內部有液體流入； 設備曾暴露在過於潮濕的環境中使用； 設備無法正常工作，或您無法通過用戶手冊來使其正常工作； 設備跌落或者損壞； 設備有明顯的外觀破損。 請不要把設備放置在超出我們建議的溫度範圍的環境，即不要低於 0°C （32°F）或高於 40°C （104°F） ，否則可能會損壞設備。 注意：若電池放置不正確，將有爆炸的危險。因此，只可以使用製造商推薦的同 一種或者同等型號的電池進行替換。請按照製造商的指示處理舊電池。 根據 IEC 704-1:1982 的規定，操作員所在位置的聲壓級不可高於 70dB(A)。 限制區域：請勿將設備安裝於限制區域使用。...
- Page 8 UNO-3483G User Manual viii...
-
Page 9: Table Of Contents
Chapter Overview..........1 Introduction ....................2 Hardware Specifications ................2 1.2.1 General ..................2 System Hardware..................3 1.3.1 I/O Interfaces ................3 1.3.2 Environment.................. 3 1.3.3 Expansion Board (Optional)............3 Safety Precautions ..................4 Chassis Dimensions.................. 4 Figure 1.1 UNO-3483G Dimensions..........4 Figure 1.2 I/O View .............. - Page 10 Connecting Power................... 18 Figure 3.1 Dual Power Connector ..........18 Inserting a iDoor..................18 Figure 3.2 Assemble the iDoor module ........18 Installing Hard Disk ................. 19 Figure 3.3 Pull up the HDD/SSD bracket ........19 Figure 3.4 HDD assemblies with bracket ........19 Installing an Interface card..............
-
Page 11: Chapter 1 Overview
Chapter Overview This chapter provides an overview of UNO-3400G series' specifica- tions. Sections include: Introduction Hardware specification Safety precautions Chassis dimensions Accessories... -
Page 12: Introduction
Introduction Advantech's UNO-3400G is an embedded Application Ready Platform (ARP) with Intel high performance 3rd generation Core i7/i3 series processor and 7-series PCH. It supports one PCI or PCI express slot, which can fulfill extensive requirements in various projects. The UNO-3400G series products provide a rich array of interfaces, including VGA... -
Page 13: System Hardware
System Hardware CPU: UNO-3483G: Intel Core® i7-3612QE (4M Cache, 2.10GHz) Memory: 8G DDR3L SDRAM burn-in ((Non-ECC, DDR3/DDR3L with one unbuffered SODIMM slot, up to 8G) Transcend/AQD-SD3L8GN16-SG 8GB Indicators: LEDs for power, SATA, LAN (active status) Storage: HDD: 2 × 2.5" SATA HDD/SSD bays, support SATA Gen3.0 ... -
Page 14: Safety Precautions
Safety Precautions The following sections tell how to make each connection. In most cases, you will sim- ply need to connect a standard cable. Warning! Always disconnect the power cord from your chassis whenever you are working on it. Do not connect while the power is on. A sudden rush of power can damage sensitive electronic components. -
Page 15: Accessories
Power Connector RJ45 LAN HDMI USB 2.0/3.0 Chassis Grounding RTC Battery iDoor Expansion Slots Reset Button HDD & PWR LED Lights PCIe Expansion Hot-Swappable HDD Figure 1.2 I/O View Accessories Please refer to the below accessories list for UNO-3400G series. ... - Page 16 UNO-3483G User Manual...
-
Page 17: Chapter 2 Hardware Functionality
Chapter Hardware Functionality This chapter shows how to setup UNO-3400G series' hardware functions, including connecting peripherals, setting switches and indicators. Sections include: Peripherals RS-232 Interface RS-422/485 Interface LAN / Ethernet Connector Power Connector Mini PCIe Socket ... -
Page 18: Introduction
Introduction The following figures show the interfaces of the UNO-3483G and the detailed infor- mation of each peripheral. Figure 2.1 UNO-3483G Dimensions Figure 2.2 Top view of UNO-3483G UNO-3483G User Manual... -
Page 19: Serial Interface (Com1/Com2)
Serial Interface (COM1/COM2) The UNO-3483G offers one standard RS-232 and one RS-422/485 serial communi- cation interface ports: COM1 and COM2 (Pin header CN31). The IRQ and I/O address of serial ports are listed as below. COM1: 3F8, IRQ4 COM2: 2F8, IRQ3 CN31 Figure 2.3 Pin header of COM1/COM2 2.2.1... -
Page 20: To Switch The Internal Sw8 According To The Placement
2.2.4 To switch the internal SW8 according to the placement Figure 2.4 SW8 Location COM2 RS422 Tx and RS485 D+/D- termination (pin1-pin8) Figure 2.5 With termination (default) Figure 2.6 Without termination UNO-3483G User Manual... -
Page 21: Lan: Ethernet Connector
COM2 RS422 Rx termination (pin2-pin7) Figure 2.7 With termination (default) Figure 2.8 Without termination LAN: Ethernet Connector The UNO-3483G is equipped with four Gigabit LAN controllers. The controller chip used is the Intel Ethernet controller with that is fully compliant with 802.1Qav, IEEE1588/802.1AS, 802.3az standards and Intel? AMT function (Intel AMT function accompanies certain SKU's of Core-i processors). -
Page 22: Hdmi Connector
HDMI Connector The UNO-3483G provides an HDMI and VGA controller for a high resolution inter- face. It supports up to full HD resolution for two independent displays. RTC Battery The RTC Battery to ensure the setting in BIOS and system clock can be kept, even with power disconnected for a short time. -
Page 23: Pci Express Mini Card Socket
2.10 PCI Express Mini Card Socket There are three sockets for full size and one half size PCI Express mini cards. The first interface (CN28) is the default defined for Mini-PCIe, (or change to mSATA by BIOS menu setting). The second (MINI1) and the third (MINI2) interface is mainly tar- get to support iDoor technology/ module for diversified application such as isolated COM port, Profibus, WLAN GPRS, 3G, mRAM and so on. -
Page 24: Pcie Slot
2.11 PCIe Slot In order to fulfill user's extensive requirements, UNO-3483G provide one PCIe x4 slot. The PCIe slot could provide user to install standard PCIe card compatible with PCIe x4, for example, USB expansion card, Ethernet expansion card...etc. Note! This PCIe slot support 25W (max). -
Page 25: Audio Jack
Press “F4” to save and exist the BIOS setup. Press “Ctrl+I” to enter RAID configuration utility when the Intel Rapid Storage Technology option ROM screen appears. Figure 2.13 Detecting RAID configuration Create a RAID volume in the RAID configuration utility. Figure 2.14 Create RAID Volume Follow the standard procedure to install OS into the RAID volume. -
Page 26: Led Indicators
2.15 LED Indicators There are four LEDs to indicate the status of the system power, storage read/write, COM1 and COM2 transmit/receive. PWR: Green means normal. HDD, Tx/Rx1~2: Flashing green means signals are being transmitted and received. 2.16 Remote Power Button (SW3) Figure 2.15 SW3 Location ... -
Page 27: Chapter 3 Initial Setup
Chapter Initial Setup This chapter introduces how to initialize UNO-3000G series. Sections include: Chassis Grounding Connecting Power Connecting a Hard Disk BIOS Setup and System Assign- ments... -
Page 28: Connecting Power
Connecting Power Connect one or two 24 VDC power source to UNO-3483G.The power source can be from either a power adapter or an in-house power source. Figure 3.1 Dual Power Connector Inserting a iDoor The UNO-3483G has dual iDoor slots for various expansions. Follow the below exploded diagram to install iDoor modules into the system. -
Page 29: Installing Hard Disk
Installing Hard Disk Follow the steps below to install a HDD/SSD into the system. Release the thumb screw and pull up the HDD/SSD bracket. Figure 3.3 Pull up the HDD/SSD bracket Screw the HDD/SSD to the bracket. Figure 3.4 HDD assemblies with bracket UNO-3483G User Manual... -
Page 30: Installing An Interface Card
Put the bracket back & secure the thumb screw. Note! Available 130 mm space upon HDD bracket. Installing an Interface card The UNO-3483G provides optional backplanes to fulfill extensive requirements in various project. These backplanes provide PCIex4 and PCI slots for compatibility with different interface cards. -
Page 31: Mounting Uno-3483G
Mounting UNO-3483G The UNO-3483G has a unique design compared to embedded PC conventions. For the highest performance product in the control cabinet PC series, the UNO-3483G is space-saving and Place & Click features, been designed for mounting on the outside of the cabinet closely to be more convenient for users. - Page 32 Step 03 Figure 3.8 Placing & Click (II) Step 04 Figure 3.9 Screw on all snaps UNO-3483G User Manual...
- Page 33 The UNO-3483G mounting enclosure on the cabinet is IP67 rated. Despite this clas- sification, the UNO-3483G is not impervious to water damage in any situation. It is important that the heat sink mounting on cabinet is closed tightly. Note the tips below carefully to prevent damage. Ensure the cabinet you use is IP67 rated, and meets the dimensions of the cut- ...
- Page 34 UNO-3483G User Manual...
-
Page 35: Appendix A System Settings And Pin Assignments
Appendix System Settings and Pin Assignments... -
Page 36: System I/O Address And Interrupt Assignment
System I/O Address and Interrupt Assignment Table A.1: Interrupt Assignments Interrupt# Interrupt source Parity error detected IRQ0 System timer IRQ1 Standard 101/102-Key or Microsoft Natural PS/2 Keyboard IRQ2 Interrupt from controller 2 (cascade) IRQ3 Communications Port (COM2) IRQ4 Communications Port (COM1) IRQ5 Available IRQ6... -
Page 37: Function Of Connectors & Switches
Figure A.2 Front view of Main/System board Function of connectors & switches The connectors and switches on the inside boards are defined as table A.2 & A.3. Table A.2: Connectors on main board Label Function Power Switch Reset SATA Power SATA2 SATA1 Audio... -
Page 38: Audio (Pin Header)
Table A.3: Connectors on System board Label Function MINI1 Mini PCIE MINI2 Mini PCIE Remote configuration COM2 configuration DCN1 Power input 12V/24V Reserved for power output, the voltage is the same as power input (DCIN1) RTC battery input DCO1 12V power output CN17 Power switch, reset, RTC battery output CN18... -
Page 39: Internal Usb
Internal USB Table A.5: CN13 Internal USB 1653005260 Part Number HD_5x2P_79_N10 Footprint PIN HEADER 2*5P 180D(M) 2.0mm SMD IDIOT-PROOF Description Pin Name A_D- B_D- A_D+ B_D+ COM1/COM2 Table A.6: CN31 COM1/COM2 Pin Name DCD1# DSR1# RXD1 RTS1# TXD1 CTS1# DTR1# RI1# 485-422_TXN-DCD# 485-422_TXP-RXD... -
Page 40: Lan1/Lan2
LAN1/LAN2 Table A.7: CN15 LAN1/LAN2 1652003274 Part Number RJ45_28P_RTB-19GB9J1A Footprint PHONE JACK RJ45 28P DIP Gold flash RTB-19GB9J1A Description Pin Name TX+(10/100),BI_DA+(GHz) TX-(10/100),BI_DA-(GHz) RX+(10/100),BI_DB+(GHz) BI_DC+(GHz) BI_DC-(GHz) RX-(10/100),BI_DB-(GHz) BI_DD+(GHz) BI_DD-(GHz) UNO-3483G User Manual... -
Page 41: External Usb2.0+Usb3.0
External USB2.0+USB3.0 Table A.8: CN19 External USB2.0+USB3.0 1654010199 Part Number USB_13P_UEA1112C-UHS6-4F Footprint Description Pin Name SSRX- SSRX+ SSTX- SSTX+ UNO-3483G User Manual... -
Page 42: External Usb2.0+Usb3.0
External USB2.0+USB3.0 Table A.9: CN20 External USB2.0+USB3.0 1654010199 Part Number USB_13P_UEA1112C-UHS6-4F Footprint Description Pin Name SSRX- SSRX+ SSTX- SSTX+ UNO-3483G User Manual... -
Page 43: Vga
A.10 Table A.10: CN23 VGA 1654000055 Part Number DBVGA-VF5MS Footprint D-SUB Conn. 15P 90D(F) DIP 070242FR015S200ZU Description Pin Name GREEN BLUE DDAT HSYNC VSYNC DCLK A.11 HDMI Table A.11: CN21 HDMI 1654010203 Part Number HDMICON_21P_845-002-217CRL Footprint Description Pin Name UNO-3483G User Manual... -
Page 44: Power Connector (Pwr)
A.12 Power Connector (PWR) Table A.12: Power connector pin assignments 1 V1+ 24 VDC Input 1 2 V2+ 24 VDC Input 2 3 V- Power Ground 4 GND Chassis Ground 5 Remote Power Button 6 Remote System Reset 7 Remote Remote Ground Table A.13: CN1 Power Switch 1655302020... - Page 45 Table A.15: CN6 SATA Power 1655001154 Part Number WF_4P_98_BOX_R1_D Footprint Description Pin Name Table A.16: CN7 SATA2 1654007578 Part Number SATA_7P_WATF-07DBN6SB1U Footprint Description Pin Name UNO-3483G User Manual...
- Page 46 Table A.17: CN8 SATA1 1654007578 Part Number SATA_7P_WATF-07DBN6SB1U Footprint Description Pin Name Table A.18: CN28/CN29 Mini PCIE 1654006715 Part Number MINIPCIE_FULL_HALF_STANDARD Footprint Description Pin Name WAKE# +3.3VSB +1.5V UIM_PWR UIM_DATA REFCLK- UIM_CLK REFCLK+ UIM_RESET UIM_VPP UNO-3483G User Manual...
- Page 47 Table A.18: CN28/CN29 Mini PCIE PERST# PERn0 +3.3VSB PERp0 +1.5V SMB_CLK PETn0 SMB_DAT PETp0 USB D- USB D+ +3.3VSB +3.3VSB +1.5V +3.3VSB UNO-3483G User Manual...
- Page 48 Table A.19: MINI 1 / MINI 2 Mini PCIE 1654006715 Part Number MINIPCIE_FULL_HALF_STANDARD Footprint Description Pin Name +3.3VSB +1.5V REFCLK- REFCLK+ UNO-3483G User Manual...
- Page 49 Table A.19: MINI 1 / MINI 2 Mini PCIE PERST# PERn0 +3.3VSB PERp0 +1.5V SMB_CLK PETn0 SMB_DAT PETp0 USB D- (MINI2 only) USB D+ (MINI2 only) +3.3VSB +3.3VSB +1.5V +3.3VSB Note! MINI1 (No Connection on pin 36/38) UNO-3483G User Manual...
- Page 50 Table A.20: CN29 (on system board) 5V power output 1655002020 Part number WF_2P_98_BOX_R1_2503-WS-2_D Footprint: Description Pin name Note! This connector support max 1.5 A. UNO-3483G User Manual...
-
Page 51: Power Input (Dcin1)
Table A.21: VO1: reserve for power output, the voltage is same as power input (DCIN1) 1655304020 Part number WF_4P_79_BOX_R1_D Footprint Description Pin name 12V/24V 12V/24V Note! This connector support max 2 A. Table A.22: CN17 power switch, reset, RTC battery output 1655000953 Part number WHL6V-49-24W1251... - Page 52 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2017...
