Hardware Functionality
This chapter shows how to setup the
UNO-2182's hardware functions,
including connecting peripherals, set-
ting switches and indicators.
Sections include:
• Peripherals
• RS-232 Interface
• RS-232/422/485 Interface
• LAN / Ethernet Connector
• Power Connector
• PS/2 Mouse and Keyboard Connector
• USB Connector
• PCMCIA: PC Card Slot
• VGA Display Connector
• Battery Backup SRAM
• Reset Button
• Power Button
• Audio
• PCI-104
