UNO-1372G/UNO-1372GH
Fanless DIN-Rail IPC with Intel® Atom™ E3845 CPU
Startup Manual
Packing List
Before you begin installing your card, please make sure that
the following items have been shipped:
1. UNO-1372G/UNO-1372GH
2. 4-pin connector for power wiring
3. 10-pin connector for digital I/O wiring
4. Din-rail mounting bracket
5. 3 x PCS screws for din-rail bracket (1930001361)
6. Wall mounting bracket
7. 4 x PCS screws for wall mounting bracket
8. 4 x PCS screws for HDD (1931030602)
9. 6 x PCS screws for mPCIe slot (1930000198)
10. Lockable I/O kit (only in UNO-1372GH-E3AE)
11. Startup manual
12. China RoHs sheet
13. Warranty card
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
For more information on this and other Advantech prod-
ucts, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our sup-
port website for UNO-1372G/UNO-1372GH at:
UNO-1372G
Register your products on our website and get 2 months
extra warranty for Free at:
http://www.register.advantech.com
Part No. 2041137200
Printed in Taiwan
UNO-1372GH
1st Edition
Feburary 2025
Packing List (Cont.)
Note:
Acrobat Reader is required to view any PDF
file. Acrobat Reader can be downloaded at: get.
adobe.com/reader (Acrobat is a trademark of
Adobe)
Caution: DANGER OF EXPLOSION IF BATTERY IS
INCORRECTLY REPLACED. REPLACE ONLY
WITH THE SAME OR EQUIVALENT TYPE
RECOMMENDED BY THE MANUFACTURER,
DISCARD USED BATTERIES ACCORDING TO
THE MANUFACTURER'S INSTRUCTIONS.
Attention: DANGER D'EXPLOSION SI LA BATTERIE EST
INEXACTEMENT REMPLACÉE. REMPLACEZ
SEULEMENT AVEC LA MÊME CHOSE OU
LE TYPE ÉQUIVALENT RECOMMANDÉ PAR
LE FABRICANT, JETTENT LES BATTERIES
UTILISÉES INSTRUCTIONS DE S SELON
FABRICANT DES'.
Specifications
Processor System
• Intel Atom E3845 1.91GHz, 2MB L2 Cache
Memory
• Built-in 4G DDR3L SDRAM
Serial Ports
• 1 x RS-232, DB9, 50bps~115.2kbps
• 1 x RS-422/485, DB9, auto flow control, 50bps~115.2kbps
Ethernet
• 2 x Intel® i210-IT GbE, 802.1Qav, 802.1AS, 802.3az
• 1 x Realtek RTL8111E GbE
Storage
• One drive bay for SATA 2.5" HDD (Compatible with
9.5mm height HDD)
Expansion
• 2 x Full-size mPCIe slot
• 1 x Mini SIM card slot
External I/O
• Display:
- 1 x VGA, supports 1920 x 1080 @ 60Hz 24bpp
- 1 x HDMI 1.4a, supports 1920 x 1080 @ 60Hz 24bpp
• USB: 2 x USB 2.0, 1 x USB 3.0
• Isolated DIO: 4-ch digital input, 4-ch digital output (2500
V
)
DC
• Audio: Line-Out
UNO-1372G/UNO-1372GH Startup Manual 1
