Dvi-I Interface; Hdmi Interface; Special Sync Interface - Quantum Data 881 User Manual

Pin
1
2
3
4
5
6
6 Chapter 1 Getting Started
Pin Signal
4 No Connection
5 Digital Ground

DVI-I interface

The DVI-I interface, available on the model 882D generator, outputs digital video for testing
DVI-compliant video displays. The DVI-I connector also provides an analog output which
can be used to test analog formats.
The DVI connector pinouts are shown in the following table.
Pin Signal Pin
1 TMDS D2- 9
2 TMDS D2+ 10
3 D2/4 Shield 11
4 TMDS D4- 12
5 TMDS D4+ 13
6 DDC Clock 14
7 DDC Data 15
8 No Connection 16

HDMI interface

The HDMI interface emulates an HDMI-compliant video display. The HDMI connector
pinouts are shown in the following table.
HDMI Type A Connector Pinouts
Signal
TMDS Data 2+
TMDS Data2 Shield
TMDS Data2-
TMDS Data1+
TMDS Data1 Shield
TMDS Data1-

Special Sync interface

Use the Special connector to output frame sync, line sync, composite sync, or a special
probe pulse. For more information, see Chapter 20,
Pin Signal
9 DDC/EDID +5 Vdc Out
10 Digital Ground
Signal Pin Signal
TMDS D1- 17 TMDS D0-
TMDS D1+ 18 TMDS D0+
D1/3 Shield 19 D0/5 Shield
TMDS D3- 20 TMDS D5-
TMDS D3+ 21 TMDS D5+
+5 Vdc 22 Clock Shield
Ground 23 TMDS Clock+
Hot Plug Detect 24 TMDS Clock-
Pin Signal
7 TMDS Data0+
8 TMDS Data0 Shield
9 TMDS Data0-
10 TMDS Clock+
11 TMDS Clock Shield
12 TMDS Clock-
Pin Signal
14 Vertical Sync
15 DDC/EDID Data Clock
Pin Signal
C1 Analog Red
C2 Analog Green
C3 Analog Blue
C4 Horizontal Sync
C5 Analog Ground
Pin Signal
13 CEC
14 Reserved (N.C.)
15 SCL
16 SDA
17 DDC/SEC Ground
18 +5 V Power
19 Hot Plug Detect
"Using Special Sync Output."
