7. To save the changes, press the Enter (Options) key. The following choices appear on
the generator's display:
Apply Settings?
Yes
To save the changes, choose the Yes item by pressing the adjacent soft key.
To exit without saving the changes, choose the No item.
To return to the Network Connection screen without saving the changes, choose the
Back item.
8. Power cycle the generator to invoke the new IP address.
To enable DHCP for auto IP address configuration of the generator:
1. Press the Tools key. The Tools menu appears on the generator's display as shown
below.
System
Sequence
Probe
AFC
2. Choose the System item by pressing the adjacent soft key. The System menu appears
on the generator's display as shown below.
*Clock
CalFactor
Network
Serial
3. Choose the Network item by pressing the adjacent soft key. The generator's IP address
and subnet mask appear on the generator's display as shown below.
IP Address
192.168.254.001
Subnet Mask
255.255.255.000
Back
No
Reports
ImgShift
Analyzer
CEC
Clone
Server
About
Gpib
