881/882 Video Test Generator User Guide (Rev A.25)

GPIB interface

The GPIB interface allows you to use the generator as a programmable video signal
source in a larger automated test system. The GPIB connector pinouts are listed in the
following table.
Pin Signal Pin
1 DIO1 7
2 DIO2 8
3 DIO3 9
4 DIO4 10
5 EOI 11
6 DAV 12
Signal Pin Signal
NRFD 13 DIO5
NDAC 14 DIO6
IFC 15 DIO7
SRQ 16 DIO8
ATN 17 REN
Shield 18 Shield
Pin Signal
19 Shield
20 Shield
21 Shield
22 Shield
23 Shield
24 Signal Ground
9
