881/882 Video Test Generator User Guide (Rev A.25)
8. Select BootNow by pressing the adjacent item selection key.
9. The following display appears:
Press UP arrow
to Boot Now
10. Press the + key to boot the generator.
The following display appears and the generator boots up.
Quantum Data
Windriver
vxWorks System Boot
Press any key for setup
11. Press the Tools key. The Tools menu appears on the generator's display as shown
below.
System
Sequence
Probe
AFC
12. Choose the System item by pressing the adjacent soft key. The System menu appears
on the generator's display as shown below.
Clock
CalFactor
Network
Serial
13. Choose the Clone item by pressing the adjacent soft key. The Clone menu appears on
the generator's display as shown below.
Capture
14. Choose the Restore item by pressing the adjacent soft key.
A progress indicator appears. This will take some time.
15. Reconfigure the generator to boot from the Flashmem using the procedures described
in
"To boot a generator that is in a stalled
16. Restart the generator.
17. If the problem persists you may have to unseat the video board from the main board:
http://www.quantumdata.com/support/videos/video.asp
Reports
ImgShift
Analyzer
CEC
Clone*
Server
About
GPib
ite
Restore
state:" on page 73.
75
