6.5 Function Map

The User Screen includes 5 function options:
1. OPEN folders under selected User folder
2. NEW (Create) a User
3. EDIT a User
4. DELETE a User
5. SYSTEM
Once a user folder is selected and the password is approved, users can:
RUN a Protocol

NEW (Create) a protocol

EDIT (VIEW) a Protocol

DELETE a Protocol

The function map is shown in Figure 9. Various functions, including Gradient, can be added to the selected/created Protocol.
6 | LABNET MULTIGENE OPTIMAX THERMAL CYCLER
OPEN
User
RUN NEW EDIT
(VIEW)
Protocol Protocol
Protocol
Insert
Delete
Advanced
Save
Figure 9. Operation flowchart.
Main Menu
User Folder
NEW EDIT
User User
Data Log
DELETE
Protocol
Date & Time
Lid Temp
Beeper
Administrator
Service Mode
Ramping Speed
Optimization
Tm Calculator
Increment
Pause
DELETE SYSTEM
User
