3.5 Function Map

The User Screen includes 5 function options; 1) VIEW folders under selected User folder,
2) NEW(Create) a User, 3)EDIT a User, 4)DELETE a User, 5)SYSTEM. Once a user
folder is selected and the password is approved, users can; 1) RUN a Protocol,
2)NEW(Create) a protocol, 3) EDIT(VIEW) a Protocol, and 4) DELETE a Protocol.
The function map is shown in Figure 9. Various functions, including Gradient, can be
added to the selected/created Protocol.
OPEN
User
RUN NEW
Protocol Protocol
NEW
User
EDIT
DELETE
(VIEW)
Protocol
Protocol
Insert
Delete
Advanced
Optimization
Increment
Pause
Save
Figure 9. Operation Flowchart
10
Main Menu
User Folder
EDIT DELETE
User User
Data Log
Date &Time
Lid Temp.
Beeper
Administrator
Service Mode
Ramping Speed
Tm Calculator
SYSTEM
