Time Increment
BBB>NEW>INCRE.
9.4.3 Pause Setting
Position your cursor on the desired temperature segment. Press F4:PAUSE to add a pause action during operation. Pause will appear on
the Temperature Segment graph. The Pause will last for 10 minutes, then the Protocol will resume the operation. To remove the Pause
setting, place the cursor under "P." Pause symbol. Press F4:PAUSE again to remove the Pause setting and its symbol.

9.5 Saving a Protocol

After all settings are entered, press F1:SAVE to store the protocol. Screen will Prompt "Please enter protocol name". A Protocol name is
required to be entered.
Max. Protocol name: 12 characters.

10.0 Editing (Viewing) a Protocol

An editing Protocol can be saved under a new name (newly created Protocol) or under the same name (edited Protocol).
Under the User's Folder, choose the Protocol to be edited. Select F3:EDIT to edit the selected Protocol. This displays the existing
Protocol and enables editing of the temperature segment and numerical values as shown below.
Refer to Section 9 Creating a New Protocol to edit the temperature segment and numerical values, and other advanced functions.
Press F1:SAVE to save the edited Protocol under the original name or F2:SAVE A to as a new protocol.
1 Tmp
3 Tmp
Temp 94.0 94.0
Time
5:00 0:30
Time Increment: + 0:00
CLEAR
F 2
F 1
8/21/2022
2 Tmp
25 Cyc
55.0 72.0
0:30 10:00
0:30
+
-
F 3 F 4
13:00
4.0
EXIT
F 5
