Labnet MultiGene OptiMax Thermal Cycler Instruction Manual page 5

Lid
Sample block
Control panel
Air vents (front)
Power cable
connector
Power switch
Product label
Air vents (rear)
Figure 2. Front view.
Figure 3. Rear view.
Lid knob
Keypad
Air vents
(left and right sides)
USB port
Brightness
adjustment knob
RS-232 port
Instruction Manual | 3
