9.4 Advanced Settings

Users can set up the following advanced functions: 1) Optimization, 2) Temperature/Time Increment/Decrement, 3) Pause.
F4:ADVANCE button, is used to enter these settings. The screen below will be displayed.
9.4.1 Optimization Temperature Setting
1. To enter an Optimization Temperature setting, place your cursor on the desired Temperature Segment. Select F2:OPTI to enter the
screen below.
2. The temperatures of all BLOCK offset are based on BLOCK #1. If you press F2:AUTO to set gradient temperature, each BLOCK will
automatically add 4°C based on the preceding BLOCK. Prior to pressing F3:AVG. users need to enter BLOCK #6 setting, and the
screen will show the calculated temperature gradient from BLOCK #1 to BLOCK #6 as show in Figure 10. This reflects the variation
of the temperature from BLOCK #1 (coolest) to BLOCK #6 (hottest).
3. All temperatures are based on BLOCK #1, and users can move the cursor to press any higher temperature (Range: 0.1°C to 24.0°C)
on BLOCK #2 to BLOCK #6.
4. Press F5:EXIT to confirm the settings. Press F1:OFF to re-enter the settings. A capital letter and High-temperature value; "G70.0",
will appear on the Temperature Segment graph and Low-temperature value will be shown on the Temp value of the section.
To remove the Optimization Temperature setting, place your cursor in the same temperature segment with "G" Gradient Temperature
symbol. Press F2:OPTI again. The screen will show each BLOCK temperature settings. Press F1:OFF to clear the Optimization
Temperature setting. Press F5:EXIT will delete the Gradient Temperature setting and its symbol.
12 | LABNET MULTIGENE OPTIMAX THERMAL CYCLER
Mike>PROTOCOL>NEW>ADV.
1 Tmp 3 Tmp 25 Cyc
Temp 94.0 94.0
Time 5:00 0:30
Enter desired temp, time or number.
OPTI.
F 2
F 1
8 /21/2022 1 1:00
2 Tmp
55.0 72.0 72.0
0:30 0:30 10:00
INCRE. PAUSE
F 3 F 4
4.0
EXIT
F 5
