Inspector 5000™ Auto Optic

Appendix B (Symbology Analysis)

Symbology Analysis Parameters

Table B-1 shows error messages that will be displayed
for each parameter type checked by the Inspector 5000.
Table B-1 (Parameter/Error Message)
Parameter
Ratio
Ratio <2 or more >3.2
Inter-Character Gap (ICG)
Invalid Data Character
Too Few Characters
I 2 of 5 Case code not 14 or 18
characters
Code 128 GS1 Case code not
14 or 18 characters or not all
numeric characters
Mod Check Digits
Bar Width Deviation Edge of
Range (Wide)
Bar Width Deviation Edge of
Range (Narrow)
Bar Width Deviation Out of
Range (Wide)
Bar Width Deviation Out of
Range (Narrow)
Addendum Parity (UPC/EAN)
ISO/ANSI Decodability
Object in Quiet Zone
Quiet Zone Too Small
<Fnc1> with Standard C128
No <Fnc1> with GS1 Selected
RJS, Minneapolis, MN
68
Appendix B
Data Analysis Message
Warning Ratio
Rejected Ratio
Bad ICG
Invalid format
Invalid format
Invalid format
Invalid format
Bad Mod. Check
Warning Wide
Warning Narrow
Rejected Wide
Rejected Narrow
Invalid Format
Warn D/bility
(DCD, in initial Pass/Fail screen)
Defects F, 50% or greater
Warning QZ/SS
Format Warning
Warn Missing F1
003-4500
