Operator's Guide
3 MIL
0.003 inches
*5 MIL
0.005 inches
6 MIL
0.006 inches
10 MIL
0.010 inches
20 MIL
0.020 inches
See Appendix I for an explanation of how to select
the correct aperture size
The next selection is Wavelength:
This selection allows you to select one of two light
wavelengths which are Red (660nm) or Infrared (925nm -
invisible). The default it RED and Infrared is used by very
few customers.
The next selection is Auto Optic number of scans:
Bar code quality varies throughout the height of a bar
code. It is best to take multiple scans from top to bottom
and average the scan grades to calculate the overall scan
grade. This parameter can be set from 1 to 10.
The next selection is Auto Optic Days Between
Calibration:
The maximum number of days allowable before the
system must be field calibrated (Auto Optic only).
The system will display a warning message one day
before expiration and after calibration expires inspection
results may be captured but the results will not be stored
in the database and may not be printed.
27
003-4500
Inspector 5000™ Auto Optic
(for Europe and Japan)
RJS, Minneapolis, MN
