Inspector 5000™ Auto Optic
Line 7
Displays the ISO/ANSI Worst Decodability character in the
barcode:
Worst Decodability
This is the character in the bar code where the worst
Decodability was measured. It is possible the worst
Decodability is in the structure part of the bar code
(character not shown in the human readable). Here are
the possible structure characters:
*LG* = Left guard bars
*RG* = Right guard bars
*CG* = Center guard bars
*AG* = Add-on guard bars
*LP* = Left pattern
*RP* = Right pattern
*ES* = Extra stop character
Line 8
Displays the ISO/ANSI Modulation letter grade and
percentage result:
Modulation
Line 9
Displays the ISO/ANSI Symbol Contrast letter grade and
percentage result:
Symbol Contrast
Line 10
Displays the ISO/ANSI Defects letter grade and
percentage result:
Defects
Line 11
Displays the ISO/ANSI Minimum Edge Contrast Pass/Fail
result and percentage result:
Minimum Edge Contrast
RJS, Minneapolis, MN
Operator's Guide
A
77%
A
79%
B
17%
Pass
61%
003-4500
44
4
