Examples Reports - RJS Inspector 5000 Operator's Manual

Operator's Guide

Examples Reports

Figure J-1 (Analysis Only data)
On 10-07-21 @ 11:16:59
10-Scan Average Analysis
Encoded bar code data
(stacked data to display
packed Subset-C
numeric characters)
*F006129501200115C
C1101685013121063B8j*
Encoded bar code data
(single line with
<*C><F1>010061162895500113210201101653<
brackets identifying
CB>8<**>
control characters)
Mod Check is:............1
Mod Check expected:......1
Scan Profile Analysis
Reference Decode...........4.0/A
Decodability.........73%...4.0/A
ISO/ANSI Results
Symbol Contrast......73%...4.0/A
See Appendix A
Refl(MIN)/Refl(MAX)..08%...4.0/A
(Bar code definitions)
Edge Contrast(MIN)...53%...4.0/A
MODulation...........72%...4.0/A
Defects..............06%...4.0/A
Grade A/4.0 using a
Application Compliance.....4.0/A
10 mil aperture and
660nm wavelength
(red) of light
Acceptable...............PASS
See the next page
for an explanation
of the Traditional
Analysis
Traditional Results
Print Contrast Signal....91% PASS
See Appendix L
Required PCS.............75%
(Bar code definitions)
Element Refl.(MAX).......80% PASS
Reflectance(MIN).........07% PASS
Passing Grade Selected.....1.5/C
Final Results.............*PASS*
003-4500
Appendix J
Inspector 5000A
Version 1.108
GS1-128
*
74
74 PASS
Overall Symbol Grade
A/10/660 4.0/10/660
Traditional Analysis
-100% Tol. +100%
--------A+++++++
Pass/Fail Analysis
99
