Operator's Guide
Line 3
Displays the ISO numeric grade, the aperture, and the
wavelength:
ISO
OVERALL GRADE
Note: YY is the aperture and XXX is the wavelength
Line 4
Displays the ANSI letter grade, the aperture, and the
wavelength:
ANSI OVERALL GRADE
Note: YY is the aperture and XXX is the wavelength
Line 5
Displays the number of scans for the current bar code that
have been captured and the total number of scans (as
selected in the Setup screen) necessary to calculate the
Overall Scan Grade:
Decodes
Line 6
Displays the ISO/ANSI Decodability letter grade and
percentage result:
Decodability
43
003-4500
Inspector 5000™ Auto Optic
3.4/YY/XXX
B/YY/XXX
3 of 10
B
56%
RJS, Minneapolis, MN
