Dgam-3-01-1*-R (Metric Bolt Tapping) Dgam-3-01-1* (Unc Bolt Tapping); Adaptor Plate, Size 05 To 03 For Pressure Up To 210 Bar (3000 Psi) - Eaton VICKERS SystemStak Manual

Installation
Dimensions
DGAM-3–01–1*–R
(Metric bolt tapping)
DGAM-3–01–1*
(UNC bolt tapping)
Adaptor plate, Size 05 to 03
for pressure up to 210 bar
(3000 psi)
5,3
(0.21)
40,5
(1.59)
4 holes for valve
mounting
bolts (see table)
Size 03 Mounting Surface
modEl tappingS For ValVE mounting boltS
DGAM–3–01–1*–R M5–6H x 12 (0.47) deep
DGAM–3–01–1* #10–24 UNC–2B x 12,7 (0.5) deep
5,6 (.22) dia. thru
13,0 (.51) spotface
to depth shown. 4
holes for mounting.
Dimensions in mm(in).
20 Eaton Vickers Solenoid Operated Directional Valves Product Catalog V-VLDI-MC011-E September 2008
Size 3 valves can frequently be
used in place of size 5 valves,
typically for pilot control func-
tions, or generally where the
system flow rate is within that
of size 3 valves.
70,0 (2.75)
31,0 14,2
(1.22) (0.56)
A
90,4
(3.56)
P T
54,0
(2.12)
B
18,3
31,75
(0.72)
(1.25)
46,0 12,0
(1.81) (0.47)
0,75
(0.03)
4 holes tapped according
to model type (see table)
84,0 (3.3)
72,0 (2.83)
19,75
(0.78)
B
P
T
A
The DGAM–3 adaptor bolts
to an existing size 5 interface
and provides a size 3 mounting
face for the smaller valves.
28,4 (1.12)
21,0 (0.83)
Size 05 Mounting Surface (seals included)
Adaptor is supplied complete with bolts for mounting
to size 5 interface:
M6 bolts with type DGAM–3–01–1*–R
1/4" –20 UNC bolts with type DGAM–3–01–1*
P T B
DGVM
6,0
16,0 (0.63)
(0.24)
6,0
(0.24)
84,0
(3.31)
72,0
(2.83)
20,0
(.787)
35,0
(1.37)
4 ports .750-16 UNF-2B
for side ports.
Size 03
P T
P T T
A B
Size 05
A
Standard T
port (T
P
Additional T
B
port (T
P
T
A
DGMS
4 ports .750-16 UNF-2B
for rear ports.
12,75 (0.5)
B
35,0
(1.38)
T
P
A
12,75 (0.5)
36,00
(1.42)
59,25
(2.33)
B A
B A
)
A
)
B
A
B
57,25
(2.25)
