SystemStak Systems . . . Easy to Understand,
Easy to Design
P
T
Figure 6
Fig. 7 represents a complete
SystemStak system, showing typical
use of functions available from this
range. The circuit diagram also shows
the use of a tapping plate for accessing
line pressure readings, and a blanking
plate to close off an unused station of a
multi-station manifold.
P
T
Figure 7
B A
B A B
B A
A B
