L alarme s est déclenché a 5 h du matin et depuis il ne fonctionne plus,de lumière au boîtiers ,seul l alarme glignotte jaune que dois je faire pour remettre en service. I ON 30 40 50 160

1 comments:

Mr. Anderson

May 14, 2025

To reset the Eaton Series I ON 30 40 50 160 alarm system after it was triggered, follow these steps:

1. Acknowledge the alarm. When an alarm becomes active, it is marked as "Unacknowledged" and, if configured, its LED will flash.
2. Use the front panel display or ProView NXG software to view the alarm condition.
3. Press the appropriate button to acknowledge the alarm (typically labeled "Operate" or similar).
4. If a timer is configured, ensure the alarm condition has cleared and the timer has expired.
5. If needed, reset counters by pressing ENTER and then ENTER again to confirm.

Note: Alarm configuration, including timer and LED settings, must be done using software.

This answer is automatically generated

Summary of Contents for Eaton Cooper Power Series

Page 1 COOPER POWER Voltage Regulators SERIES Effective April 2018 MN225003EN Supersedes July 2017 CL-7 Voltage Regulator Control; Installation, Operation, and Maintenance Instructions CL-7 Regulator Control ALARM WARNING VOLT LIMITER HIGH DIAG ERROR OUT-OF-BAND HIGH OUT-OF-BAND LOW VOLT LIMITER LOW ENTER AUTO TAP BLOCKED REVERSE POWER EDIT VOLT REDUCTION...
Page 2 CONTENTS OF THIS DOCUMENT SHALL NOT BECOME PART OF OR MODIFY ANY CONTRACT BETWEEN THE PARTIES. In no event will Eaton be responsible to the purchaser or user in contract, in tort (including negligence), strict liability or otherwise for any special, indirect, incidental or consequential damage or loss whatsoever, including but not limited to...
Page 3: Table Of Contents
Contents DISCLAIMER OF WARRANTIES AND LIMITATION OF LIABILITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . II SAFETY FOR LIFE .
Page 4: Table Of Contents
SECTION 5: CONTROL PROGRAMMING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 Quik-Start setup .
Page 5: Table Of Contents
SECTION 8: TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158 External check .
Page 6: Safety Information
FOR LIFE FOR LIFE Eaton meets or exceeds all applicable industry standards relating to product safety in its Cooper Power™ series products. We actively promote safe practices in the use and maintenance of our products through our service literature, instructional training programs, and the continuous efforts of all Eaton employees involved in product design, manufacture, marketing, and service.
Page 7: Product Information
For additional Description information, please contact your Eaton representative. The CL -7 voltage regulator control from Eaton's Cooper Power series incorporates the latest in digital technology Acceptance and initial inspection to provide accurate, rapid, and dependable control of a step-voltage regulator.
Page 8 CL-7 Voltage Regulator Control Multi-phase Active Display LEDs Status Indicators USB Drive Data Port and CL-7 Regulator Control ALARM USB Type B PC Data Port Control Function Switch WARNING VOLT LIMITER HIGH Manual Raise/Lower Switch DIAG ERROR OUT-OF-BAND HIGH Supervisory Off Switch OUT-OF-BAND LOW Drag-Hand Reset Switch VOLT LIMITER LOW...
Page 9: Section 1: Control Front Panel
This section is similar to that of other controls in bushings using an approved voltmeter is zero . If both Eaton's Cooper Power series CL line. Refer to Figure 2. neutral indicators do not indicate neutral or there is a...
Page 10 CL-7 Voltage Regulator Control Connecting power to external source terminals 120 Vac applications to an Eaton's Cooper Power series 120 V control Option 1: Option 2: The control box assembly is connected to earth ground The control box assembly is floating. This is a typical shop to provide protection to operations personnel.
Page 11 Neutral connected to ground at panel to shunt HV to LV faults/leakage to Earth Ground. Can't be removed. Figure 2 . 120 Vac application with Eaton's Cooper Power series 120 V Control—Option 1 CL-7 Control Panel 1:1 Isolation To assure isolation from Earth...
Page 12 CL-7 Voltage Regulator Control 240 Vac applications to an Eaton's Cooper Power series 120 V control Option 1: Option 2: The control box assembly/panel is connected to earth The control box assembly is floating. This is a typical shop ground to provide protection to operations personnel. This is...
Page 13 Earth Neutral connected to ground at panel to shunt HV to LV faults/leakage to Earth Ground. Can't be removed. Figure 4 . 240 Vac application with Eaton's Cooper Power series 120 V Control—Option 1 CL-7 Control Panel 2:1 Isolation Transformer...
Page 14 CL-7 Voltage Regulator Control 240 Vac applications to and Eaton's Cooper Power series 240 V control Option 1: Option 2: The control box assembly/panel is connected to earth The control box assembly is floating. This is a typical shop ground to provide protection to operations personnel. This is...
Page 15 Earth. Neutral connected to ground at panel to shunt HV to LV faults/leakage to Earth Ground. Can't be removed. Figure 6 . 240 Vac application with Eaton's Cooper Power series 240 V Control—Option 1 CL-7 Control Panel Factory Installed 1:1 Isolation...
Page 16: Upper Panel (Black)
CL-7 Voltage Regulator Control Upper panel (black) The CL -7 control utilizes a nested menu structure, items are structured with a main menu and then one, two, three, or four sub-menus. The final sub-menu in any of the menus Display contains the control parameters.
Page 17 CL-7 Voltage Regulator Control Enter Key Scroll Arrow Key Back Arrow Key Forward Arrow Key Scroll Arrow Key Edit Key Escape Key Alphanumeric Keypad Function Key Symbol Key Figure 9 . Alphanumeric, scrollable keypad with user-definable Metering-PLUS and shortcut options Keypad Alphanumeric and symbol keys The front panel interface for the CL -7 control uses a 19-key After pressing the FUNC or EDIT keys, the alphanumeric...
Page 18 CL-7 Voltage Regulator Control Short-cut hot-keys Forward Set Voltage FC 1 ● ● The keypad can be configured to create shortcut access Forward Band Width FC 2 ● ● to a variety of commonly used Metering-PLUS, menu and Forward Time Delay FC 3 parameter displays.
Page 19 CL-7 Voltage Regulator Control Multi-phase Indicators Alarm Indicators User Defined LEDs Status Indicators User Defined LED Description Slide-out Hot-Key Description Slide-out USB Drive and PC Data Ports Communication Indicators Figure 12 . Alarm, communication indicators and slide- Figure 11 . Status indicators and USB ports out hot-key map Indicator LEDs Data ports...
Page 20: Section 2: Control Installation
CL-7 Voltage Regulator Control Section 2: Control installation Table 1 . Control Specifications Description Specifications WARNING Physical Size* Height Hazardous Voltage . To protect personnel from surges while operating the control, follow these control Single-phase Model 11.5 in. (292 mm) enclosure grounding procedures: a) If the enclosure is Multi-phase Model 17.5 in.
Page 21: Operational Check
In-service check ote: For use with a non-Eaton's Cooper Power series With the control programmed for basic operation, perform voltage regulator, refer to the manufacturer’s manual an operational check of manual and automatic operation.
Page 22: Field Calibration Check
CL-7 Voltage Regulator Control Place the CONTROL FUNCTION switch in the AUTO/ line. A true RMS meter, however, will include these REMOTE position. After the time delay period, the harmonic voltages in its calculations of the RMS control should cause the regulator to step up to the voltage.
Page 23: Removal From Service
CL-7 Voltage Regulator Control Removal from service WARNING Refer to the appropriate regulator manual as indicated on the regulator nameplate for further information. Explosion Hazard . To stop the regulator on the neutral position, the CONTROL FUNCTION switch should be returned to Off during the switching operation from Determining neutral position positions 1R or 1L to position neutral .
Page 24: Removal Of Control
CL-7 Voltage Regulator Control Removal of control Replacement of control The control may be removed from the regulator with the WARNING regulator energized. Record settings, etc., to facilitate replacement of the control. Flashover Hazard . Do not pull open the current shorting To open the control, unscrew the captive knob(s) on the left switch C until the TB3 (or TB2 if present) connection is side of the panel.
Page 25: Section 3: Initial Control Programming
CL-7 Voltage Regulator Control Section 3: Initial control programming Basic programming Set the parameters in Table 3 to program the control for basic operation. Continue with the steps in Table 4 This section explains each step for properly completing to program the control for reverse power and additional initial control programming settings on a CL -7 voltage features.
Page 26: Multi-Phase Programming
CL-7 Voltage Regulator Control Table 4 . Programming for reverse power and additional features Function code Description Instructions Regulator Identification FUNC, 141, ENTER, EDIT, Value, ENTER Requirements for Reverse Sensing Mode without IDPTs Source Voltage Calculation FUNC, 39, ENTER, EDIT Scroll - On; Off, ENTER Required for Reverse Sensing Modes Reverse Set Voltage FUNC, 51, ENTER, EDIT, Value, ENTER...
Page 27: Programming And Reconfiguring For Different Voltage Systems
CL-7 Voltage Regulator Control Programming and reconfiguring for different voltage systems Reconfiguring a voltage regulator for a new system voltage requires more than just programming the control. System voltage changes will require control programming, ratio correction transformer (RCT) connection changes and in some cases, a change in the control winding (PT) tap connection inside the regulator tank through the hand-hole cover.
Page 28: Allowable System Voltages And Calculation Of Overall Pt Ratio
CL-7 Voltage Regulator Control Program the control as required for the new system EXAMPLE: If a 60 Hz, 7620 V regulator is to be used on a voltage: system with a nominal voltage of 2500 V, the following is determined: Set FC 41 to for the system configuration (Wye, Delta Leading, Delta Lagging).
Page 29 CL-7 Voltage Regulator Control 2075 4485 1384 Figure 15 . Nameplates, 60 Hz regulator and 50 Hz regulator shown INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225003EN April 2018...
Page 30: Determination Of Leading Or Lagging In Delta-Connected Regulators
CL-7 Voltage Regulator Control Determination of leading or lagging in delta- For one regulator: Set FC 41 to the value which produced the reasonable power factor. connected regulators For a regulator to operate properly when connected phase For two regulators in open delta: See the example in to phase, it is necessary for the control to be programmed Table 6.
Page 31: Section 4: Control Operation
These operation (the standard mode set at FC 42) is selected, the characteristics are described in Control operating control response on Eaton's Cooper Power series voltage modes in this section of the manual. regulator is as follows:...
Page 32: Security System
CL-7 Voltage Regulator Control Security system Remote security override The security (password) system implemented on the CL-7 The remote security override feature allows for a temporary control is structured into four levels. This permits selective override of control security through SCADA. This can be access to the various parameters as dictated by the active used in cases where local operators are not provided with security level.
Page 33: Basic Control Operations
CL-7 Voltage Regulator Control Basic control operations To provide the regulator with the capability to regulate at a projected load center, the control has line-drop- compensation elements within it. This circuitry usually Set voltage consists of a current transformer (CT), which produces a The set voltage is the voltage level to which the control current proportional to the load current, and resistive (R) and will regulate on the 120 V or 240 V base.
Page 34 CL-7 Voltage Regulator Control into band. When the voltage goes in-band, the timer is Internal PT ratio decremented at the rate of 1.1 seconds for every second The CL -7 control does not require a ratio correction elapsed, until it reaches zero. transformer (RCT) for the internal differential PT (IDPT).
Page 35: Quik-Start Setup
CL-7 Voltage Regulator Control Section 5: Control programming Quik-Start setup Refer to Table 8 for a quick start up for basic regulation. Please note the following Function Code information when Use the keypad to program the control. A Quik-Start™ using the Quik-Start settings. setup is given for programming for basic regulation.
Page 36 CL-7 Voltage Regulator Control Table 8 . Quik-start set-up for basic regulation Function code Description Instructions Security Security FUNC, 99, ENTER, Password (Admin), ENTER Forward settings Forward Set Voltage FUNC, 1, ENTER, EDIT, Value, ENTER Forward Bandwidth FUNC, 2, ENTER, EDIT, Value, ENTER Forward Time Delay FUNC, 3, ENTER, EDIT, Value, ENTER Forward Line Drip Comp.
Page 37: Function Menu
CL-7 Voltage Regulator Control Function menu Refer to Table 9 for the nested menu structure: Main Menu, Sub-Menus, and Parameter Table 9 . Function menu Level 1 Level 2 Level 3 Level 4 Function Main Menu Sub-Menu Sub-Menu Sub-Menu Parameter Code *SETTINGS *Forward Direction Forward Set Voltage Forward Bandwidth...
Page 38 CL-7 Voltage Regulator Control Table 9 . Function menu (continued) Level 1 Level 2 Level 3 Level 4 Function Main Menu Sub-Menu Sub-Menu Sub-Menu Parameter Code *SETTINGS (Cont.) *Calendar/Clock System Calendar and Clock UTC Time Zone Date Format Time Format _Multi-Phase Config Multi-Phase Feature Multi-Phase Mode Multi-Phase VRs Configured...
Page 39 CL-7 Voltage Regulator Control Table 9 . Function menu (continued) Level 1 Level 2 Level 3 Level 4 Function Main Menu Sub-Menu Sub-Menu Sub-Menu Parameter Code Tap To Neutral *FEATURES (Cont.) *Tap To Neutral Tap to Target *Tap To Target Target Tap Position SOFT-ADD-AMP Limits *SOFT-ADD-AMP SOFT-ADD-AMP High Limit...
Page 40 CL-7 Voltage Regulator Control Table 9 . Function menu (continued) Level 1 Level 2 Level 3 Level 4 Function Main Menu Sub-Menu Sub-Menu Sub-Menu Parameter Code *FEATURES (Cont.) *Alternate Config *Alternate Configuration 2 Forward Set Voltage (Cont.) Forward Bandwidth Forward Time Delay Fwd Line Drop Comp.
Page 41 CL-7 Voltage Regulator Control Table 9 . Function menu (continued) Level 1 Level 2 Level 3 Level 4 Function Main Menu Sub-Menu Sub-Menu Sub-Menu Parameter Code *FEATURES (Cont.) *Alternate Config _Alternate Configuration 3 Forward Set Voltage (Cont.) Forward Bandwidth Forward Time Delay Fwd Line Drop Comp.
Page 42 CL-7 Voltage Regulator Control Table 9 . Function menu (continued) Level 1 Level 2 Level 3 Level 4 Function Main Menu Sub-Menu Sub-Menu Sub-Menu Parameter Code *FEATURES (Cont.) *Leader/Follower Leader/Follower Leader/Follower State Leader/Follower Mode Leader/Follower Designation Follower Devices Configured Leader/Follower Tap Wait Timer Leader/Follower Timeout Leader/Follower Retry Delay Leader/Follower Retries...
Page 43 CL-7 Voltage Regulator Control Table 9 . Function menu (continued) Level 1 Level 2 Level 3 Level 4 Function Main Menu Sub-Menu Sub-Menu Sub-Menu Parameter Code *FEATURES (Cont.) *Voltage Sag Monitoring Voltage Sag Monitoring Level1 Threshold Level1 Recovery Level1 Threshold Timer Value Level1 Recovery Timer Value Duration of Last Level1 Duration of Longest Level1...
Page 44 CL-7 Voltage Regulator Control Table 9 . Function menu (continued) Level 1 Level 2 Level 3 Level 4 Function Main Menu Sub-Menu Sub-Menu Sub-Menu Parameter Code *COUNTERS *Operations Counter Total Operations Last Counter Change Enable Interval Counters Last 24 Hours Operations Last 30 Days Operations Current Month Operations Last Month Operations...
Page 45 CL-7 Voltage Regulator Control Table 9 . Function menu (continued) Level 1 Level 2 Level 3 Level 4 Function Main Menu Sub-Menu Sub-Menu Sub-Menu Parameter Code *METERING (Cont.) *Instantaneous (Cont.) Total kW Load Total kvar Load Motor Voltage Load Voltage Secondary (L-N) Load Voltage Secondary (L-L) Source Voltage Secondary (L-N) Source Voltage Secondary (L-L)
Page 46 CL-7 Voltage Regulator Control Table 9 . Function menu (continued) Level 1 Level 2 Level 3 Level 4 Function Main Menu Sub-Menu Sub-Menu Sub-Menu Parameter Code *METERING (Cont.) *Forward Demand (Cont.) Maximum Tap Position Maximum Percent Regulation Minimum Tap Position Minimum Percent Regulation Forward Source Voltage High Forward Source Voltage Low Forward Source Voltage Present...
Page 47 CL-7 Voltage Regulator Control Table 9 . Function menu (continued) Level 1 Level 2 Level 3 Level 4 Function Main Menu Sub-Menu Sub-Menu Sub-Menu Parameter Code *COMMUNICATIONS *Comm Port #1 *Comm Port #1 Configuration Protocol / Port Type LoopShare Communications ProView NXG Session ProView NXG Address Ethernet Switch On Comm Port #1 Serial Bridge Mode...
Page 48 CL-7 Voltage Regulator Control Table 9 . Function menu (continued) Level 1 Level 2 Level 3 Level 4 Function Main Menu Sub-Menu Sub-Menu Sub-Menu Parameter Code *COMMUNICATIONS *Comm Port #1 (Cont.) *IEC 60870-5-104 IEC104 Server Listen Port (Cont.) IEC104 Common Address IEC104 Single Command Op Mode IEC104 Select Before Exec Time IEC104 Response Timeout (t1)
Page 49 CL-7 Voltage Regulator Control Table 9 . Function menu (continued) Level 1 Level 2 Level 3 Level 4 Function Main Menu Sub-Menu Sub-Menu Sub-Menu Parameter Code *COMMUNICATIONS *Comm Port #2 (cont.) *DNP3 Network (Cont.) DNP Listening Port Number (Cont.) DNP Use Port From Request Initial Unsol UDP Dest Port DNP Keep Alive Timeout DNP Outbound Port Type...
Page 50 CL-7 Voltage Regulator Control Table 9 . Function menu (continued) Level 1 Level 2 Level 3 Level 4 Function Main Menu Sub-Menu Sub-Menu Sub-Menu Parameter Code *COMMUNICATIONS *TCP/IP Re-init TCP IP Socket Re-Init (Cont.) TCP IP Socket Re-Init Timeout *LoopShare LoopShare Comms State LoopShare Comm Table Assignment LoopShare Comm Tx Delay LoopShare Comm Timeout...
Page 51 CL-7 Voltage Regulator Control Table 9 . Function menu (continued) Level 1 Level 2 Level 3 Level 4 Function Main Menu Sub-Menu Sub-Menu Sub-Menu Parameter Code *DIAGNOSTICS *Test LEDs (No Items) *Control Firmware Version Firmware Database Version FPGA Version Digital Hardware Revision BootUtility Version BootLoader Version USB Device Connected...
Page 52 CL-7 Voltage Regulator Control Table 9 . Function menu (continued) Level 1 Level 2 Level 3 Level 4 Function Main Menu Sub-Menu Sub-Menu Sub-Menu Parameter Code *MENU SYSTEM *Security Access Security Override Password "Operate" Password "Modify" Password "Admin" Remote Security Override Timer Remote Security Override Mode *Language Language Selection...
Page 53: Function Codes
Admin 999999 XXXXXX •On an Eaton's Cooper Power series voltage regulator, the total operations counter is activated by detecting tap-changer motor operation, which is determined by sensing current flow in the holding switch circuit. •It may also be incremented through operations counter circuitry on non-Eaton's Cooper Power series manufactured tap changers.
Page 54 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 004 Fwd Line Drop Comp. Resistance Volts/% View Modify -96.0 96.0 XX.X Volts •The resistive line-drop compensation value is used to model the resistive line voltage drop between the regulator and the center of regulation.
Page 55 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 008 Compensated Volt. Secondary Volts View XXX.X Volts •This is the calculated voltage at the center of regulation, referred to the secondary. •This is based on the resistive compensation setting (FC 4 or FC 54), reactive compensation setting (FC 5 or FC 55), and the load current.
Page 56 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 013 Power Factor View -X.XXX •This is the power factor of the primary circuit, as represented by the phase difference between the line current and voltage.
Page 57 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 016 kvar Load Kvar View XXXX.X kvar •This is the total kilovolt-amperes reactive (reactive power) drawn by the load. The reactive power adds to losses on the line, yet does not do any work.
Page 58 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 020 Forward Load Voltage Present Volts View XXX.X Volts •This is the present reading of secondary output voltage of the regulator, as a demand value, according to the demand time interval at FC 46 021 Fwd Compensated Volts...
Page 59 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 023 Power Factor at Max Forward kVA “-----” View X.XXX (Invalid) MM-DD-YYYY HH:MM:SS •This is the instantaneous power factor of the load at the first occurrence of the maximum kVA demand value, since last reset.
Page 60 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 025 Forward kW Load Present View XXXX.X kW •This is the present value of the load kW, as a demand value, according to the demand time interval at FC 46.
Page 61 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 029 Forward Source Voltage Low Volts View Operate Reset* XXX.X Volts MM-DD-YYYY HH:MM:SS •This is the minimum source voltage of the regulator since last reset, as a demand value, according to the demand time interval at FC 46.
Page 62 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 031 Rev Compensated Voltage High Volts View Operate Reset* XXX.X Volts MM-DD-YYYY HH:MM:SS •This is the highest value of the calculated secondary voltage at the center of regulation during reverse power flow since last reset, as a demand value, according to the demand time interval at FC 46.
Page 63 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 032 Reverse Load Current Low Amps View Operate Reset* XXX.X Amps MM-DD-YYYY HH:MM:SS •This is the lowest value of the load current during reverse power flow since the last reset, as a demand value, according to the demand time interval at FC 46.
Page 64 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 034 Reverse kVA Load Low View Operate Reset* XXXX.X kVA MM-DD-YYYY HH:MM:SS •This is the lowest value of the load kVA during reverse power flow since last reset, as a demand value, according to the demand time interval at FC 46.
Page 65 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 036 Reverse kvar Load High kvar View Operate Reset* XXXX.X kvar MM-DD-YYYY HH:MM:SS •This is the highest value of the load kvar during reverse power flow since last reset, as a demand value, according to the demand time interval at FC 46.
Page 66 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 038 Master Reset View Operate •Only demand metering forward and reverse; maximum and minimum raise and lower; tap position values and associated time/date stamps are reset to their corresponding present demand values at FC 38.
Page 67 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 043 System Line “-----” Voltage Volts View Modify 1200 36000 (Invalid) XXXXX Volts •The control is designed to operate on primary system voltages from 1200 V to 36000 V.
Page 68 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 045 Adaptive ADD-AMP 5% Limit View Modify XXX % •Adaptive ADD-AMP setting found in the Limit Switch Settings chart on the nameplate at the 5% Level.
Page 69 •This function code identifies the tap-changer type. Changing this function code changes the control’s sampling rate to accommodate varying tap-changer types. •Options include: Eaton's Cooper Power series QD8; Eaton's Cooper Power series QD5; Eaton's Cooper Power series QD3; Eaton's Cooper Power series Spring Drive; Eaton's Cooper Power series Direct Drive;...
Page 70 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 052 Reverse Bandwidth Volts/% View Modify X.X Volts •The bandwidth is defined as that total voltage range, around the set voltage, which the control will consider as a satisfied (in-band) condition during reverse power flow.
Page 71 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 056 Reverse Sensing Locked Mode View Modify Forward Locked Forward •The control offers ten different response characteristics for power flow operation. See Section 6: Control Features: Reverse power operation for more information on the reverse sensing modes.
Page 72 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 070 Voltage Reduction Mode View Modify •The control has three voltage reduction modes available. Options include: Off; Local/ Digital Remote;...
Page 73 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 076 # of Pulse Reduction Steps View Modify •Up to ten steps of remotely activated voltage reduction are available. The voltage reduction steps are activated when FC 70 is set to Remote/Pulse and a momentary pulse is applied to the appropriate input terminal.
Page 74 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 081 High Voltage Limit Volts/% View Modify 130.0 105.0 135.0 XXX.X Volts •The high voltage limit for Voltage Limiter. •When the voltage-limiting function is activated (FC 80), the control will prevent the output voltage of the regulator from exceeding this value.
Page 75 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 088 Factory Access Mode View Modify Disabled Disabled •This function is used to diagnose the control when an extended communications module is in use.
Page 76 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 090 CO1 = Inactive CO2 = Inactive View CO3 = Inactive CO4 = Inactive •Provides a status of the auxiliary output contacts and will display the status as Inactive or Active.
Page 77 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High (095) Self-Test Complete View xx-xx-xxxx x:xx:xxa (Pass) •This function code will display the results of the last self-test. 096 Password "Operate"...
Page 78 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 101 Last 24 Hours Operations Reset* to View Admin XXXXX MM-DD-YYYY HH:MM:SS •Number of operations in last 24 hours (updated hourly and on every tap change). •This counter is reset by pressing ENTER and then ENTER again to confirm.
Page 79 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 110 Tap Position Sync Counter Reset* to View Admin XXXXX MM-DD-YYYY HH:MM:SS •A count of the number of times the control tap position indication (TPI) was synchronized either at neutral or when the regulator was able to tap up or down when TPI was at 16R or 16L respectively.
Page 80 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 128 Minimum Percent Regulation View Operate Reset* XX.X % MM-DD-YYYY HH:MM:SS •This is the highest percentage that the regulator has lowered the input voltage since last reset.
Page 81 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 132 Average Minimum Tap Position View MM-DD-YYYY HH:MM:SS •The instantaneous metering display of the average minimum tap position for all phases when in multi-phase operation.
Page 82 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 134 Fwd Load Current Reactive Present View XXX.X Amps MM-DD-YYYY HH:MM:SS •Demand metering present value for the reactive portion of the current for forward power. 135 Rev Load Current Real High Amps...
Page 83 2.5 kV and current ratings above 875 A. •Type D – Series duplex auto transformer design or Series AX. Used on Eaton's Cooper Power series voltage regulators with voltage rating of 5.0 kV and 7.62 kV and current rating above 875 A.
Page 84 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 147 Neutral Sync Retry Count View Modify •If the control tap-position indication (TPI) is at 1R or 1L and the control taps toward the neutral position but does not detect neutral, the control will keep the tap-position indication at 1R or 1L and allow attempts to tap down or up to synchronize TPI with the actual tap position.
Page 85 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 170 Tap To Neutral View Modify •This setting will enable the Tap To Neutral Feature. Once the feature is enabled, it can be activated using analog inputs, digital SCADA, or configurable logic.
Page 86 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High •When a battery is connected to the control, this will display the voltage and current readings of the battery found while running the battery test routine.
Page 87 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High •Sets a VR1 wait timer for use with the Multi-phase modes that require a gang operation (meaning that all tap changers must be on the same position).
Page 88 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 211 Sequencing Interval Seconds View Modify XX Seconds •The sequence interval for the multi-phase display and status LEDs on the control HMI. The LEDs will alternately display the status of each connected device for the specified interval.
Page 89 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 265 Com 2 Reset* to Rx Errors View Operate XXXXX •Count of Receive Errors from Com 2. 300 PMT Mode A State View...
Page 90 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 327 PMT Mode B Current Limit View Modify XXX % •The PMT Mode B is enabled at or below the current limit setting, defined as a percentage of the CT primary rating.
Page 91 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 416 Leader/Follower Timeout Seconds View Modify XX Seconds •The length of time in seconds before the Leader returns to starting tap position if a Follower device does not tap.
Page 92 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 450 Alternate Config Mode View Modify •This will turn on Alternate Configurations and designate a mode of operation. The options are: Off;...
Page 93 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 465 Reverse Set Voltage Volts View Modify 120.0 100.0 135.0 XXX.X Volts •Reverse Set Voltage for Alternate Configuration 1. 466 Reverse Bandwidth Volts...
Page 94 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 477 Remote #2 Value View Modify 10.0 XX.X % •The Remote latch #2 Voltage Reduction Value for Alternate Configuration 1. 478 Remote #3 Value View Modify...
Page 95 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 489 Voltage Limiter Delay Seconds View Modify XX Seconds •The Voltage Limiter Delay for Alternate Configuration 1. 490 Time Between Taps Seconds...
Page 96 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 508 Rev Line Drop Comp. Resistance Volts View Modify -96.0 96.0 XX.X Volts •Reverse Line Drop Compensation Resistance for Alternate Configuration 2.
Page 97 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 521 Present Voltage Reduction Step View •The Remote Pulse Voltage Reduction Present Voltage Reduction Step for Alternate Configuration 2.
Page 98 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 550 Forward Set Voltage Volts View Modify 120.0 100.0 135.0 XXX.X Volts •Forward Set Voltage for Alternate Configuration 3. 551 Forward Bandwidth Volts...
Page 99 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 562 Reverse Current Sense Threshold View Modify •The Reverse Current Sense Threshold for Alternate Configuration 3. 563 Auto Operation Blocking Status View...
Page 100 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 574 SOFT-ADD-AMP Low Limit View Modify •The SOFT-ADD-AMP Low Limit for Alternate Configuration 3. 575 Voltage Limiter Mode View...
Page 101 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 602 Level1 Recovery View Modify 75.0 71.0 100.0 75.0 % •After a level 1 voltage sag has occurred, this is the level at which the voltage is said to have recovered from the sag.
Page 102 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 614 Level2 Recovery mSec View Modify 30000 Timer Value 500 mSec •The minimum time duration that must be met by a sag recovery in order to record a level 2 sag recovery.
Page 103 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 626 Duration of Cycles View Operate Longest Level3 0 Cycles MM-DD-YYYY HH:MM:SSp •A date and time stamped record of the longest duration recorded for the Duration of Last Level 3 (FC 625) voltage sag.
Page 104 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 647 Fault Level1 Threshold Timer mSec View Modify 30000 20 mSec •This setting defines the minimum time duration over which the Level 1 Fault Detect Threshold Current must occur for a fault to be recorded.
Page 105 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 654 Duration of Last Level2 Cycles View Operate 0 Cycles 01/01/1970 12:00:00a •A display with date and time stamped of the duration in cycles of the last recorded Level 2 fault since last reset.
Page 106 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 659 Duration of Longest Level3 Cycles View Operate 0 Cycles 01/01/1970 12:00:00a •A display with date and time stamped of the duration of the longest recorded Level 3 fault since last reset.
Page 107 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 752 Source Voltage Secondary (L-N) Volts View ----- Volts •This is a Delta Calc instantaneous metering value for the Source Voltage Secondary from Line to Neutral.
Page 108 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 761 Load Voltage Angle (L-L) Degrees View ----- Degrees •This is a Delta Calc instantaneous metering value for the Load Voltage Angle from Line to Line.
Page 109 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 800 Serial Bridge Mode View Modify Disabled Disabled •This parameter enables the Serial Bridge communications mode. The options include: Disabled;...
Page 110 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 801 Serial Tx Disable Delay MilliSec View Modify 3000 XXXX mSec •For Com 1, when the control is set for transmit control handshaking, a delay may be required between the time when the data transmission is terminated and the transmit enable signal is disabled.
Page 111 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 810 DNP RBE Master View Modify 1234 65519 XXXXX •This is the Com 1 setting for the DNP3 device number to be used as the destination for any unsolicited reports by DNP3 events.
Page 112 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 811 DNP Use Port From Request View Modify Enabled Enabled •This is the Com 1 setting that enables the control to use the source IP port number from the last request as the destination port number.
Page 113 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 812 IEC101 Link Address Size View Modify •This is the Com 1 setting for the number of octets to be used for the value of the link address.
Page 114 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 813 IEC104 Single Command Op Mode View Modify •This is the Com 1 setting that defines if the control will respond directly (Direct mode) to Single Command Operation commands or if a "select"...
Page 115 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 815 2179 Ignore Master Address View Modify Enabled Disabled •This is the Com 1 setting that allows the device to accept commands and requests from masters other than that listed in the Master Device Address field.
Page 116 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 830 Protocol / Port Type View Modify Serial DNP Serial DNP •Protocol and Port setting for Com 2. Not all options are resident on the control, some will require additional hardware to enable.
Page 117 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 831 Serial Tx Disable Delay MilliSec View Modify 3000 XXXX mSec •For Com 2, when the control is set for transmit control handshaking, the user may require a delay between the time when the data transmission is terminated and the transmit enable signal is disabled.
Page 118 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 840 DNP IED Slave 2 View Modify 65519 65519 XXXXX •This is the Com 2 setting for the DNP3 device number to be assigned to the connected CL-7 control.
Page 119 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 841 DNP Keep Alive Timeout View Modify 3600 65535 XXXXX Seconds •This is the Com 2 setting for the time after which a DNP3 Data Link Layer status request will be sent if no message is received from the master (enter 0 to disable).
Page 120 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 842 IEC101 Object Address Size View Modify •This is the Com 2 setting for the number of octets to be used in the value of the object address.
Page 121 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 843 IEC104 Response Timeout (t1) Seconds View Modify XXXXX Seconds •This is the Com 2 setting for the time-out value for the transmission of data or test messages.
Page 122 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 845 2179 User Map CL-7 Selection View Modify Default CL-7 Default Event •The selection of the active 2179 protocol map for Com 2. The available options are: User 1;...
Page 123 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 920 Firmware Version View X.X.X •A display of the firmware version currently active on the control. 921 Firmware Database Version View...
Page 124 CL-7 Voltage Regulator Control Table 10 . Function codes (continued) Security Level Key Entry Limit Unit of Parameter Measure To Read To Write To Reset Default Value High 950 USB Memory Drive View View Save Cust Basic •This command saves the group of settings defined as the Basic settings from a control onto a USB memory device.
Page 125: Special Functions
CL-7 Voltage Regulator Control Special functions Enter security code – FC 99 Use these functions to perform commands through the A security code must be entered to enable parameter editing menu or function code system. at the appropriate level. Entering FC 99... Function Code Master reset –...
Page 126: Sequence Of Events (Soe)
CL-7 Voltage Regulator Control Sequence of events (SOE) This section covers Alarm displays; for more information on programming alarms, see the Alarms section of document Use the Sequence of Events menu item to access a list MN225015EN CL-7 Regulator Control ProView NXG of events.
Page 127: Power-Up/Reset Conditions
Displayed when listing alarms or events: (MORE...) • Self-Test Complete. (LAST...) • VR1 No Neutral Sync Signal! (ATTENTION...LAST) Consult Section 8: Troubleshooting or contact your Eaton representative for assistance with specific self-test messages. INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225003EN April 2018...
Page 128 CL-7 Voltage Regulator Control Displayed when an alarm is to be acknowledged or Displayed when indicating that changing Internal PT ratio is unacknowledged by the user: not applicable because Vin PT configuration is invalid: (ACKNOWLEDGE) (INVALID VIN CONFIG) • • (UNACKNOWLEDGE) Displayed when indicating inconsistencies between the •...
Page 129: Calendar/Clock
CL-7 Voltage Regulator Control Section 6: Control features See Table 10 in Section 5: Control programming for information on the function codes associated with demand metering. Calendar/clock Integral to several functions of the control is an internal Demand task operation real-time calendar/clock. The clock maintains the year, month, day, hour, minute and seconds, within 1 second.
Page 130: Tap Position Indication (Tpi)
FC 27 . The minimum tap position since last reset the source-side voltage. When using an IDPT on an Eaton's (lower drag hand value of the present tap position) and its Cooper Power series voltage regulator, the source voltage date and time are stored at FC 28.
Page 131: Reverse Power Operation
CL-7 Voltage Regulator Control the other values are already available. In determining power direction the control uses one of two methods, depending upon the reverse sensing mode in use On the control back panel, when no source or differential and the current level detected. In most cases, the control PT are present, the connection that would be the input for senses the real component of the current, then determines one of these PTs if they were present is tied to the load-...
Page 132 CL-7 Voltage Regulator Control forward current exceeds 2% of the CT primary rating, the Band edge indicators control idles on the last tap position held and the band edge are turned off and tap indicators will turn off. The control will also go into an auto changing is inhibited tap blocking state and display Rev Pwr Mode on the Load when real component...
Page 133 CL-7 Voltage Regulator Control OPERATION: See Figure 25. When the control is set to the Bi-directional mode Reverse Idle mode, the control will regulate in the forward The Bi-directional setting for Reverse Sensing Mode is direction (from source bushing to load bushing) when the recommended for applications where forward and reverse real component of system load current exceeds a threshold power are possible.
Page 134 CL-7 Voltage Regulator Control exceeds the 1% threshold in the forward direction, and then the parameter scaling reverts back to normal and the Reverse Power indicator turns off. Normal Reverse Operation FC 51-55 OPERATION: See Figure 28. When the control is set to the Neutral Idle mode, the control will regulate in the forward direction (from source bushing to load bushing) when the real component of system load current, in the forward...
Page 135: Reactive Bi-Directional Mode
CL-7 Voltage Regulator Control Co-generation mode The Co-generation setting is intended for applications where distributed generation is present on the load bushing side of the voltage regulator, and where reverse power as a result of feeder switching is not possible. When the control is set for co-generation, a measured voltage from the load bushing is required, but a source voltage is not required.
Page 136 CL-7 Voltage Regulator Control Tap changing inhibited when total current is Normal Reverse within operating thresholds. Operation FC 51-55 Bias regulation in direction of power before indeterminate state was entered. 0 OT OT 0 Real Current (% of C.T. Primary) Real Current (% of C.T.
Page 137 CL-7 Voltage Regulator Control Load bushing voltage decreases one percent or more of Bias Co-Generation mode ● ● the nominal secondary voltage after two quick lower taps When FC 56 is set for Bias Co-Generation, a source voltage if the control is out of band high and was in the forward is required, either measured or calculated.
Page 138 CL-7 Voltage Regulator Control Figure 34 . Loop configured system with Co-Gen facility . Tie switch is open; stiff bus on the source bushings of the regulators and true current flow from source bushing to load bushing . Figure 35 . Loop configured system with Co-Gen facility . Tie switch is closed . Stiff bus on the load bushing of voltage regulator A with true current flow from load to source .
Page 139 CL-7 Voltage Regulator Control METERING: In a co-generation environment, when current OPERATION: When the control is set for Bias level is above the Reverse Current Sense Threshold in the Co-Generation, if the current flow exceeds the Reverse forward direction, metering will be recorded for forward Current Sense Threshold in the forward direction, the current flow.
Page 140: Reverse Co-Generation Mode
CL-7 Voltage Regulator Control Reverse Co-generation mode METERING: See Figure 39. Always regulates in the reverse direction except that load center voltage is calculated based The stand-alone use of the Reverse Co-generation mode is upon the forward line-drop compensation settings (FC 4 intended for applications where normal voltage regulation and FC 5) when the fixed 1% forward metering threshold is occurring in the reverse direction (on the source bushing...
Page 141: Multi-Phase Voltage Regulation
CL-7 Voltage Regulator Control Multi-phase voltage regulation Multi-phase parameters The CL -7 voltage regulator control is capable of controlling Once the control and control box are configured, the up to three (3) voltage regulators with the use of a single multi-phase functionality is turned on using FC 200.
Page 142 CL-7 Voltage Regulator Control Multi-phase control display The regulator settings are set individually for each regulator. When entering the settings, scroll through the display for The CL-7 control is able to cycle through displays for settings each regulator by pressing the right arrow key. The multi- and metering information.
Page 143: Deltacalc Feature
CL-7 Voltage Regulator Control DeltaCalc feature The CL -7 Multi-Phase (MP) control opens up new applications unavailable with individual single-phase controls. The single control now has access to the metering and phasor information from all connected voltage regulators. This measured data can be used to calculate metering values unavailable on single-phase connected controls, without the addition of external metering transformers.
Page 144: Voltage Limiter
CL-7 Voltage Regulator Control Voltage limiter bushings. For example, to regulate the voltage between phase A and phase C, the phase A regulator would have The voltage limiter feature is used to place both a high to have knowledge of the voltage between the SA and SC and low limit on the output voltage of the regulator.
Page 145: Voltage Reduction
CL-7 Voltage Regulator Control upper and lower band edges. When the output voltage is conditions. Configurable Logic Activate ADD-AMP is within this "grey zone", the control will not perform any tap controlled by the configurable logic capabilities of the CL-7 changes the would take the output voltage over the limit.
Page 146 CL-7 Voltage Regulator Control values, upload settings which are specific to the control I.D. Active control security level number, and view data. The entire control database may be If the local operator changes the control active security downloaded. level to Operate level or above, or security override is set to override the Operate level or higher, this does not inhibit Analysis of the data allows the user to verify the control any SCADA activity.
Page 147 CL-7 Voltage Regulator Control Analog remote/latching mode 120 Vac This feature is set at FC 70. Up to three independent values of voltage reduction are possible. Levels 1, 2, and 3 are programmed at FC 73, FC 74, and FC 75, respectively. Voltage Reduction input 1 activates the voltage reduction programmed at FC 73;...
Page 148 CL-7 Voltage Regulator Control Tap-To-Target Raise Blocking Tap To Target is similar to Tap To Neutral except that with Relay Tap To Target a regulator can be tapped to and held at any tap position until the feature is deactivated. As with Tap To Neutral, the feature must first be enabled and then Lower activated.
Page 149 Since this method keeps the control in automatic operation, MN225015EN, CL -7 Regulator Control ProView NXG Auto-Inhibiting is not used. An advantage of this method is Software Programming Guide or contact your Eaton that it can be applied to many different models of controls representative.
Page 150 CL-7 Voltage Regulator Control his page is intentionally left blank. INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225003EN April 2018...
Page 151: Metering-Plus Feature
CL-7 Voltage Regulator Control Section 7: Advanced control features Figure 49 . Operation analysis using Metering-PLUS feature Metering-PLUS feature The Out-of-Band High and Out-of-Band Low LEDs are used to indicate an out-of-band condition. The Metering-PLUS feature was designed to allow immediate access to basic control information.
Page 152 CL-7 Voltage Regulator Control EXAMPLE 2: EXAMPLE 3: Comp Voltage 115.0 Load Voltage 115.0 Band 108.0-112.0 Limiter Off Using Func 51-55 Load Voltage = 115.0 V Compensated Voltage = 115.0 ● ● ● ● Voltage-Limiting Mode = Off Rev. Set Voltage = 110.0 V ●...
Page 153: Communications
CL-7 Voltage Regulator Control Table 11 . Blocking condition priorities Priority LCD display text (1=Highest) Automatic blocking condition when… (Line 4) Control Function switch is in Off or Local Manual position. Blocked: Cntrl Switch In Voltage Averaging or Ganged Max Deviation Alt Mode in multi-phase (MP) applications for non-lead phase devices Blocked: Multiphase in Lead Phase Regulation.
Page 154 CL-7 Voltage Regulator Control The fourth line is used to display the physical P .I. ADD-AMP EXAMPLE 4: settings corresponding to the physical position indicator. Tap Position Physical ADD-AMP always takes precedence over ote: At Limit soft. SOFT-ADD-AMP -12, 14 P.I.
Page 155 CL-7 Voltage Regulator Control EXAMPLE : 12345ALL.cl7 To use the function, insert a USB memory device, access FC 950 and press ENTER. The control LCD will display the default file name and the word (CONFIRM). The file name can be edited at this time. Press ENTER again to confirm and the save the file using the name displayed.
Page 156: Protocols
CL-7 Voltage Regulator Control (SAVING...), and the control will save the configuration the user to name the file and a prompt to CONFIRM the data to the memory device. If a file already exists on the operation. Pressing ENTER again will create the settings memory device with the same name, the words (REPLACE file.
Page 157: Configurable Logic
CL-7 Voltage Regulator Control Configurable logic Auxiliary input and output Configurable Logic is a powerful tool since it provides Up to two auxiliary I/O Modules can be added as options to the user with the means to configure general logic the CL -7 control (Figure 51).
Page 158 CL-7 Voltage Regulator Control Remote Terminal Unit (RTU) CL-7 Control Box CL-7 Back Panel Control Supplied Whetting Voltage 120 Vac CL-7 Control Optical Isolation IN1-1 IN1-2 Optical Isolation IN2-1 IN2-2 Optical Isolation IN3-1 IN3-2 Optical Isolation IN4-1 IN4-2 Control NO-1 Logic Relay COM-1...
Page 159 CL-7 Voltage Regulator Control Table 12 . Contact I/O option module input ratings Description Rating Minimum Detection Level: 10 V (ac rms or dc) (50 or 60 Hz) (Using control-supplied whetting Voltage is recommended) Maximum Applied Voltage: 250 Vac, rms, or 125 Vdc Nominal Input Loading: 2 mA per input (internally current limited) Typical Control Response Time:...
Page 160: Alarms
CL-7 Voltage Regulator Control Alarms The Data Alarm type is activated based upon the condition of an analog (numeric) parameter being above An alarm is a binary (On/Off) flag that is activated when a or below a threshold value. The operations counters user-defined condition is true.
Page 161: Time-On-Tap™ Feature
CL-7 Voltage Regulator Control TIME-ON-TAP™ feature The TIME-ON-TAP™ feature logs the percentage of time spent on each tap-changer position. The TIME-ON-TAP data is only viewable using ProView NXG software and is presented in bar graph format; see Figure 54. Figure 54 . TIME-ON-TAP sample graph INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225003EN April 2018...
Page 162: Preventive Maintenance Tapping
When PMT Mode A is performed on a Quik-Drive tap- the amount of life already used. changer, this entire operation will take approximately one Duty Cycle Monitor is active only on Eaton's Cooper ote: second. The user can monitor how much time is left prior...
Page 163: Voltage Sag Monitoring
CL-7 Voltage Regulator Control Voltage sag monitoring The voltage sag monitor compares the voltage regulator load voltage with a reference value and determines if the load voltage has dropped below a defined threshold level for a defined period of time. The concept is based on the voltage quality curve defined by the Computer Business Equipment Manufacturer’s Association (CBEMA), which is meant as a guideline for the kind of voltage deviation that...
Page 164: Fault Detection
CL-7 Voltage Regulator Control Fault detection The fault detection feature will compare system load current The Fault Detection feature can be enabled using FC 640 on measured by the voltage regulator with a reference value, the control HMI or by checking a box in the Fault Detection and determine if the load current rises above a defined fault dialog box in ProView NXG.
Page 165: Heater
CL-7 Voltage Regulator Control The Fault Detect feature can also be used in conjunction Customer supplied battery power with Status Alarms. When levels of fault detection are The CL -7 control can be powered using a substation battery included in the list of active alarms and one of the fault with a voltage of 48 to 125 Vdc.
Page 166: Defining The Problem
. VR-T213 .0 Check the voltage-disconnect knife switch V1, V6 (if When using the CL -7 control with an Eaton's Cooper Power present), and the current shorting knife switch C on the series regulator, refer to document MN225008EN VR-32 back panel in the control enclosure.
Page 167 CL-7 Voltage Regulator Control No Data Acquisition!—Data failed to be acquired over If there is no neutral light and no neutral light signal at ● ● a 1 second time period (data is acquired every 512 terminal NL, verify that the regulator is in neutral. For the microseconds, if no data is acquired in one second it regulator to be in neutral, the position indicator should be indicates a problem).
Page 168: Tap-Changer Operation Troubleshooting
CL-7 Voltage Regulator Control Indication messages when using edit key Tap-changer operation troubleshooting The following indication messages can occur when using The regulator will not operate manually or automatically the Edit key: Connect a voltmeter between R1 and G. Set the (Improper Security) message will display while ●...
Page 169 Vac. regulator. The nameplate indicates what type of tap- changer is on Eaton's Cooper Power series regulator. A voltage reading between R1 and G of 0 V or a mV FC 49 must be set for the type of tap-changer (Spring reading while giving a lower signal is a sign of a bad Drive, Direct Drive, QD8, QD5, QD3).
Page 170 CL-7 Voltage Regulator Control The regulator operates manually but operates incorrectly when Voltage Regulator Tap-Changer Installation and set on automatic Maintenance Instructions. If all appears to be in order, the problem is most likely in the control, not Manually run the regulator to the neutral position. Check for in the holding switch.
Page 171: Metering Troubleshooting
CL-7 Voltage Regulator Control Control calibration No band indicators If the band indicators are not working when the voltage is WARNING out-of-band, check the following: Explosion Hazard . Verify that both the neutral light and Check FC 56, Reverse Sensing Mode. If FC 56 is set to the position indicator hand indicate neutral when the Lock Forward and there is reverse power, the indicator tap-changer is physically in the neutral position .
Page 172 CL-7 Voltage Regulator Control ote: When installing an Eaton's Cooper Power series control on a non-Eaton's Cooper Power series voltage regulator, the control MUST have the calibration process performed. To calibrate the control on the non-Eaton's Cooper Power series regulator the internal power (System Voltage) must be applied.
Page 173: Section 9: Appendix
CL-7 Voltage Regulator Control Section 9: Appendix Table 14 . VR-32 tap connections and voltage levels Table 15 . VR-32 tap connections and voltage levels (60 Hz) (50 Hz) Regulator Nominal Test Overall Regulator Nominal Test Overall Ratio-Adjusting Data Ratio-Adjusting Data Voltage Single Terminal...
Page 174 CL-7 Voltage Regulator Control Table 16 . ADD-AMP capabilities of 60 Hz ratings † Load Current Ratings (A) Regulation Range (Wye and Open Delta) ±10% ±8.75% ±7.5% ±6.25% ±5% Regulation Range (Closed Delta) Rated Volts Rated kVA ±15% ±13.1% ±11.3% ±9.4% ±7.5% 2500...
Page 175 † 55/65 °C rise rating on VR-32 regulators gives an additional 12% increase in capacity if the tap- changer’s maximum current rating has not been exceeded. For loading in excess of the above values, please refer to your Eaton representative. * Regulators are capable of carrying current corresponding to rated kVA when operated at 7200 V.
Page 176: Wiring Diagrams And Schematics
CL-7 Voltage Regulator Control Wiring diagrams and schematics CT Shorting Switch Control Cable Current Transformer (Toroidal Coil) Differential Potential Transformer Drag Hand Reset External Source Terminals Ground Integrated into Terminal Board Holding Switch Lower Holding Switch Raise Indicator Reset Solenoid (Position Indicator) Junction Box on the Regulator Cover Junction Box Terminal Board...
Page 177 CL-7 Voltage Regulator Control INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225003EN April 2018...
Page 178 CL-7 Voltage Regulator Control Auto-Transformer Terminal Board CT Shorting Switch Control Cable Current Transformer (Toroidal Coil) Differential Potential Transformer Drag Hand Reset External Source Terminals Ground Integrated into Terminal Board Grounded to Back Panel Holding Switch Lower Holding Switch Raise Indicator Reset Solenoid (Position Indicator) Junction Box on the Regulator Cover...
Page 179 CL-7 Voltage Regulator Control ote: Portion of schematic shown in dotted enclosures is located in regulator tank. INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225003EN April 2018...
Page 180 CL-7 Voltage Regulator Control Drag Hand Reset External Source Terminals Holding Switch Lower Holding Switch Raise Indicator Reset Solenoid (Position Indicator) Portion of schematic shown in dotted ote: Junction Box on the Regulator enclosures is located in regulator tank. Cover Junction Box Terminal Board on the Cover Figure 64 .
Page 181 CL-7 Voltage Regulator Control Neutral Light Switch Lower Limit Switch (Position Short Circuit Protection Potential Opening Device Indicator) Control Terminal Board Power Switch Lower Logic Switch (Tap- Tap-Changer Terminal Board Ratio Correction Transformer Changer) Motor Voltage Removable Ground in Junction Lower Safety Switch Voltage Regulator Motor Capacitor...
Page 182 CL-7 Voltage Regulator Control Figure 65 . Multi-phase metering schematic INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225003EN April 2018...
Page 183 CL-7 Voltage Regulator Control Current Transformer (Toroidal Coil) CT Protection Device Drag Hand Reset External Source Terminals Junction Box on the Regulator Cover Junction Box Terminal Board on the Cover Neutral Light Potential Opening Device Power Switch Ratio Correction Transformer Short Circuit Protection Control Terminal Board Sensing Voltage...
Page 184 CL-7 Voltage Regulator Control Figure 66 . Standard back panel signal circuit INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225003EN April 2018...
Page 185 CL-7 Voltage Regulator Control CONTROL PHASE-A CABLE (CCA) CCA (BLU/BLK) CAPACITOR-1 CCA (BLK/WHT) CCB (BLU/BLK) CAPACITOR-2 CCB (BLK/WHT) 151617 202122 CCA (GRN) CCC (GRN) 1819 CCB (GRN) CCC (RED) CCC (BLU/BLK) 121314 CAPACITOR-3 CCC (BLK/WHT) TB7-9 (RED) 1 2 3 4 5 6 1 2 3 4 5 6 7 8 9 10 111213141516171819202122...
Page 186 CL-7 Voltage Regulator Control This page is intentionally left blank. INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225003EN April 2018...
Page 187 CL-7 Voltage Regulator Control This page is intentionally left blank. INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225003EN April 2018...
Page 188 United States Eaton.com/cooperpowerseries © 2018 Eaton All Rights Reserved Eaton is a registered trademark. Printed in USA For Eaton‘s Cooper Power series product Publication No. MN225003EN information, call 1-877-277-4636 or visit: All trademarks are property www.eaton.com/cooperpowerseries. April 2018 of their respective owners.
