Installation Dimensions in mm (inches)
DGMFN-3-X-***(-***)-4*
DGMFN-3-Y-***(-***)-4*
DGMFN-3-Z-***-4*
Models with type W adjuster
To adjust valve setting, slacken off locknut and turn
screw . Re-tighten locknut after completing
adjustment.
Line A or line T adjustment
(according to model type)
40
(1.57)
E max.
3,5 (0.14)
4 holes through: Ø5,3 (0.21 dia)
47,6
46
(1.87)
(1.8)
45 (1.8)
max.
Type H adjuster
Ø32 (1.26 dia)
M4 locking screw
5
2 ( / ) A/F hex. socket
64
T
A
B
P
12,7 (
Torque to 25-30 Nm (18-22 lbf ft)
A max.
B max.
Ø3 (0.12 dia)
4 off "O" seals supplied for this interface
P
B
A
T
39 (1.54)
76 (3)
C max.
Turn clockwise to decrease flow (increase restriction);
counter-clockwise to increase flow (reduce restriction).
Model
DGMFN-3-X-A*W-4*
DGMFN-3-X-A*W-B*W-4*
DGMFN-3-X-B*W-4*
56 (2.2) DGMFN-3-Y-A*W-4*
max. DGMFN-3-Y-A*W-B*W-4*
DGMFN-3-Y-B*W-4*
DGMFN-3-Z-P*W-4*
DGMFN-3-Z-T*W-4*
21
Line B or line P adjustment
(according to model type)
5
4 ( / ) A/F hex. socket
32
1
/ ) A/F hex. locknut .
2
E max.
A
121 (4.76)
–
–
121 (4.76)
–
–
–
–
T
A
B
P
D max.
47 (1.85)
max.
B C D
– – –
– 167 (6.6) –
122 (4.8) – –
– – –
– 167 (6.6) –
122 (4.8) – –
– – 123 (4.8) 16,75 (0.7)
– – 123 (4.8) 23,25 (0.9)
E
16,75 (0.7)
16,75 (0.7)
16,75 (0.7)
23,25 (0.9)
23,25 (0.9)
23,25 (0.9)
