Appendix

Spare parts data

Refer to service drawing
I–3886–S for spare parts
and kit information.

Seal kits

For valves with spool indi-
cator switch, model types
DG4V-3-*A-M-S*-60:
kit no. 859049
For other models seal kits
vary according to type of
coil fitted:
For "U" type coil:
kit no. 858995
For "F" type coil:
kit no. 858996
Each seal kit covers
Note:
a variety of models and may
have redundant seals for a
particular model.

Mass, approx. kg (lb)

DG4V-3 and "U" "F"
DG4V-3S (DC) coils coils
Single sol. valve 1,6 1,8
(3.5) (4.0)
Double sol. valve 2,2 2,3
(4.8) (5.0)
DG4V-3 and "U" "F"
DG4V-3S (AC) coils coils
Single sol. valve 1,5 1,6
(3.3) (3.5)
Double sol. valve 1,8 2,0
(4.0) (4.4)
Single sol. 2,0 2,0
valve w/ position (4.4) (4.4)
switch

Solenoid Coils

AC coils
Code Voltage/
frequency
Full power coils:
A 110V/50 Hz
B 110/120V/50/60 Hz
C 220V/50 Hz
D 220/240V/50/60 Hz
Low power coils:
BL 110/120V/50/60 Hz
DL 220/240V/50/60 Hz
DC coils (Standard and high performance)
Code Voltage
Full power coils:
G 12V
H 24V
Low power coils:
GL 12V
HL 24V

Mounting Attitude

No restrictions except for
no-spring, detented models
DG4V-3-*N and DG4V-3S-*N
which should be mounted
with the spool axis horizontal.
These model types may be
affected by severe vibration
or shock, especially if a sole-
noid is not held energized.
Eaton Vickers Solenoid Operated Directional Valves Product Catalog V-VLDI-MC011-E September 2008
Standard performance
"U" type "F" type
02-101725 02-101730
02-101726 02-101731
02-101727 02-101732
02-101728 02-101733
N/A N/A
N/A N/A
"U" type "F" type "SP1" type
507847 508172 02–111246
507848 508173 02–111248
507855 508175 N/A
507852 508174 N/A
High performance
"U" type "F" type
507825 508166
507833 508169
507826 508167
507834 508170
598562 698563
866455 866457
"SP2" type "KU" type
02-111166 02–140394
02-111168 02–140395
N/A N/A
N/A N/A
25
