Eaton VICKERS SystemStak Manual page 18

Installation Dimensions in mm (inches)
40
(1.57)
23
(0.9)
3,5 (0.14)
4 holes through: Ø5,3 (0.21 dia)
47,6
46
(1.87)
(1.8)
DGMPC-3-(D)AB*-(D)BA*-4*
T
A
B
P
101 (4) max.
Ø3 (0.12 dia)
4 off "O" seals supplied for this mounting face
P
B(B1)
A(A1)
T
39 (1.54)
76 (3)
18
13
(0.51)
DGMPC-3-(D)AB*-4*
T
A
B
P
12 (0.47)
97 (3.82)
DGMPC-3-(D)BA*-4*
97 (3.82)
13
(0.51)
