CD Automation REVO C 2PH 1100A User Manual page 49

REVO C
2PH from 1100A to 2100A
Parameter Name
Rtx Scale
Set
parameter to be represented by the
full scale of the analog output. See
the table below
Recommended
Retransmit Retransmission
Scaling
Set Point 100
xV where x is the
V Output Nominal Line
Voltage
xA where x is
I Output the Nominal Line
Current
Power 100
Parameter Name
Rtx Type
Choose type of signal for the retransmission output
Parameter Name
Start Disp
Choose which parameter is displayed on the home
page at power-up
Description
the value of
Resulting Signal
(4 to 20 mADC)
4mADC = 0%
20mADC = 100%
4mADC = 0V
20mADC = xV
4mADC = 0A
20mADC = xA
4mADC = 0%
20mADC = 100%
Description
Option
4-20mA
0-10V
0-20mA
DEFAULT: 0-10V
Description
Option
Current
Volts Out
Power
DEFAULT: Voltage
Default
retransmitted
0
Resulting Signal
(0 to 20 mADC)
0mADC = 0%
20mADC = 100%
0mADC = 0V
20mADC = xV
0mADC = 0A
20mADC = xA
0mADC = 0%
20mADC = 100%
Value
0
1
2
1
Value
0
1
2
1
49
User's manual
Modbus
Range Unit
Address
0 to 9999 124
Resulting Signal
Max Value
(0 to 10 VDC)
0VDC = 0%
10VDC = 100%
0VDC = 0V
10VDC = xV
0VDC = 0A
10VDC = xA
0VDC = 0%
10VDC = 100%
Modbus
Default
Address
1 69
Modbus
Default
Address
1 60
Par.
Type
Read
Write
100.0
999.9
999.9
100
Par.
Type
Read
Write
Par.
Type
Read
Write
